Quick Details
-
Brand Name:
-
CNAMSTR
-
Model Number:
-
Single-phase
-
Max. Current:
-
100A
-
Electrical life::
-
100,000time
-
Position of lever:
-
60-0-60
-
Rated current:
-
QS5 Cam Starter (QS5-100A)
-
Motor control capacity::
-
10HP
-
Certification:
-
IEC
Quick Details
-
Whether the smart:
-
NO
-
Max. Voltage:
-
500V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
CNAMSTR
-
Model Number:
-
Single-phase
-
Max. Current:
-
100A
-
Electrical life::
-
100,000time
-
Position of lever:
-
60-0-60
-
Rated current:
-
QS5 Cam Starter (QS5-100A)
-
Motor control capacity::
-
10HP
-
Certification:
-
IEC
QS5 Cam Starter (QS5-100A)
Packaging & Delivery
Packaging Details: Export standard carton box .
Delivery Detail: 1 to 2 weeks after your deposit .
Specification:
QS5 Cam Starter 100A
ISO9001 Certificate
QS5 Cam Starter 100A
Application
QS5 can starter is mainly used to start forward or backward and stop directly three-phase asynchronous electric motor with AC 50Hz, voltage up to 500V and capacity up to 7.5-30KW. It can also be used for changeover from one kind of circuit to another.
Specification:
| Type | Mark |
Rated
current(A) |
Motor control
Capacity(HP) |
Electrical
life(times) |
Mechanical
life(times) |
Frequency
of Operation (per hr) |
Applications |
Position
of lever |
| QS5-15A | 1-O | 15 | 5.5 | 100000 | 250000 | 200 |
On-off
switching |
0-60 |
| QS5-30A | 30 | 10 | ||||||
| QS5-15A | 1-O-1 | 15 | 5.5 |
Forward &
recerse |
60-0-60 | |||
| QS5-30A | 30 | 10 | ||||||
| QS5-15P/3 | 1-O-2 | 15 | 5.5 |
For 3 pole two
circuit |
60-0-60 | |||
| QS5-30P/3 | 30 | 10 | ||||||
| QS5-63A | 1-O | 63 | 22 | 80000 | 200000 | 180 |
On-off
switching |
0-60 |
| QS5-100A | 100 | 30 | ||||||
| QS5-63N | 1-O-1 | 63 | 22 |
Forward &
recerse |
60-0-60 | |||
| QS5-100N | 100 | 30 | ||||||
| QS5-63P/4 | 1-O-2 | 63 | 22 |
For 4 pole two
circuit |
60-0-60 | |||
| QS5-100P/4 | 100 | 30 | ||||||
| GZ-16 | 1-O-2 | 15 | 5.5 | 100000 | 250000 | 200 |
For 3 pole
& 4 pole two circuits |
60-0-60 |
Sample:
1.Free charge sample: Could provide,freight collect.
2.Samples time: Need 7-15 days to preparing the samples after receiving the payment.
3.Samples payment term: T/T.
Quality Guarantee:
Strictly quality control before leave factory.
Advantage:
1.Low MOQ: 50~100PCS.
2.New design Accepted: As your requirement.
3.Good Service: Customer as.
4.Good Quality: Strict quality control and good reputation.
5.Fast & Cheap Delivery: Big discount from express agent (Long-term Contract).
