We have 10 years of customization experience, such as logo, color, pattern, packaging,own design, thank you card, label, etc. We
also have various power of power staion. Please contact us.
Meet your various needs. Our strength lies low MOQ, 3~7 days sample, fast delivery.
Please contact us to tell your needs.
- Product Details
- {{item.text}}
Quick Details
-
Controller Type:
-
MPPT
-
Special Features:
-
Type C, Flashlight, Cigar Lighter
-
Model Number:
-
T1200
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Trend
-
Applicable Scenarios:
-
Travel, RV, home emergency, dormitory, outdoor live
-
Product name:
-
Multi-function power supply
-
Battery Capacity:
-
1038.96Wh(280800mAh)
-
Rated Power:
-
1000W
-
Rated voltage:
-
110V-240V
-
Function:
-
Quick Charge Support, LED Display, LCD screen, LED lighting
-
Overpower Protection:
-
1100W
-
AC Voltage Range:
-
Solar Energy(18~24VDC),Adapter(19~24VDC),Vehicle charger(12~15VDC)
-
Solar Charging Max Power:
-
200W
-
Solar Charging Time:
-
5H
Quick Details
-
Power Source:
-
AC Adaptor, Car, Solar Panel
-
Battery Type:
-
LiFePO4
-
Inverter Type:
-
Pure Sine Wave
-
Controller Type:
-
MPPT
-
Special Features:
-
Type C, Flashlight, Cigar Lighter
-
Model Number:
-
T1200
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Trend
-
Applicable Scenarios:
-
Travel, RV, home emergency, dormitory, outdoor live
-
Product name:
-
Multi-function power supply
-
Battery Capacity:
-
1038.96Wh(280800mAh)
-
Rated Power:
-
1000W
-
Rated voltage:
-
110V-240V
-
Function:
-
Quick Charge Support, LED Display, LCD screen, LED lighting
-
Overpower Protection:
-
1100W
-
AC Voltage Range:
-
Solar Energy(18~24VDC),Adapter(19~24VDC),Vehicle charger(12~15VDC)
-
Solar Charging Max Power:
-
200W
-
Solar Charging Time:
-
5H
Recommend Products
Products Description
Specification
|
Model
|
|
T300
|
T600
|
T1200
|
||
|
AC Output
|
Output Rated Voltage
|
100~120VAC 、220~240VAC
|
|
|
||
|
|
Output Wave
|
Pure sine wave
|
|
|
||
|
|
Output Rated Power
|
300W
|
500W
|
1000W
|
||
|
|
Overpower Protection
|
350W
|
550W
|
1100W
|
||
|
|
Output Rated Frequency
|
50Hz/60Hz ±3Hz
|
|
|
||
|
|
Inverse Efficiency
|
〉92%
|
|
|
||
|
|
Output Short circuit protection
|
Available，Short circuit removal，Automatic release
|
|
|
||
|
|
Over-Temperature Protection
|
Protection starts when radiator temperature over 65℃.
|
|
|
||
|
|
Operate
|
Press AC button 1-2S for ON/OFF switch, The screen displays "AC" icon
|
|
|
||
|
Battery Features
|
Cell Type
|
18650
|
|
|
||
|
|
Total capacity
|
83200mAh
|
135200mAh
|
280800mAh
|
||
|
|
Energy capacity
|
291.7Wh
|
500.24Wh
|
1038.96Wh
|
||
|
|
Battery Pack Method
|
4S8P
|
4S13P
|
4S27P
|
||
|
Charge Performance
|
Adapter charging Voltage
|
Solar Energy（18~24VDC），Adapter（19~24VDC),Vehicle charger（12~15VDC）
|
|
|
||
|
|
Adapter Max. Charging Power
|
120W
|
120W
|
200W
|
||
|
|
Solar charging Voltage
|
Solar Energy（18~24VDC），Adapter（19~24VDC),Vehicle charger（12~15VDC）
|
|
|
||
|
|
Solar charging Method
|
Built-in MPPT algorithm, High Efficiency Solar Charging
|
|
|
||
|
|
Single-channel charging time
|
3Hs
|
5Hs
|
5Hs
|
||
|
Discharge Performance
(DC) |
4 USB output
|
1*TYPE-C 100W, 1*TYPE-C 20W,2*USB-A QC 3.0 18W
|
|
|
||
|
|
12V DC Output DC5521
|
12V7A
|
|
|
||
|
|
Cigarette Lighter Output
|
12V10A
|
|
|
||
|
LED lighting
|
Four gears
|
low light, high light, SOS, strobe mode
|
|
|
||
|
BMS features
|
Rated current
|
30A
|
50A
|
100A
|
||
|
|
Protection function
|
1. Overcharge protection; 2. Over discharge protection;3. Temperature protection;
4. Overcurrent protection;5. Short circuit protection;6. SOC calculation
|
|
|
||
|
Running noise
|
|
＜30dB
|
|
|
||
|
Weight and Dimension
|
Mainframe weight
|
|
5.8KG
|
9.7KG
|
||
|
|
Mainframe size
|
|
209*171*221mm
|
209*173*303mm
|
||
|
|
Package weight
|
|
7.8Kg
|
11.7Kg
|
||
|
|
Package size
|
|
315*285*320mm
|
405*301*330 mm
|
||
|
Certification
|
|
CE/FCC/ROSH/PSE/UN3.3/MSDS/CDG
|
|
|
||
