- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
VisionStar
-
Model Number:
-
VS-V5540IR-IP
-
Image Sensor:
-
8.0M 1/2.7"SC8239 Black light illumination CMOS sensor
-
Resolution:
-
8MP 3840*2160@15fps
-
Lens:
-
Board lens 3.6mm
-
Infrared Leds:
-
15pcs
-
Night Vision:
-
up to 15 Meters
-
Waterproof:
-
IP66
-
Video Compression:
-
H.265
-
Feature:
-
network ip camera
-
Technology:
-
AI Face detection, motion detection
-
surveillance home camera:
-
cctv camera poe
Quick Details
-
Special Features:
-
Human Motion Tracking, Face detection, NIGHT VISION, Motion Detection, Waterproof / Weatherproof
-
Function:
-
NIGHT VISION, Waterproof / Weatherproof, Wide Angle, Vandal-proof
-
Customized support:
-
Online technical support, Customized logo, OEM, ODM
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
VisionStar
-
Model Number:
-
VS-V5540IR-IP
-
Image Sensor:
-
8.0M 1/2.7"SC8239 Black light illumination CMOS sensor
-
Resolution:
-
8MP 3840*2160@15fps
-
Lens:
-
Board lens 3.6mm
-
Infrared Leds:
-
15pcs
-
Night Vision:
-
up to 15 Meters
-
Waterproof:
-
IP66
-
Video Compression:
-
H.265
-
Feature:
-
network ip camera
-
Technology:
-
AI Face detection, motion detection
-
surveillance home camera:
-
cctv camera poe
Product Description
Specification
Features:
(1). Waterproof Outdoor Bullet CCTV IP camera
(2). 1/3" CMOS sensor for 4.0MP
(3). 1/2.8" CMOS sensor for 5.0MP,
1/2.7" CMOS sensor for 8.0MP
(4). Ultra HD resolution, clear and fine images
(5). Support 2D/3D noise reduction, digital wide dynamic
(6). Advanced H.265/H.264 video compression,Super low rate,high definition quality of image
(7). Support access third party CCTV NVR
(8). Support various mobile monitoring(iPhone,Android)
(9). Provide web, CMS, center platform management software
(10). Support cloud technology, easy to achieve network penetration, fro in-line and alarm information pushed
Model
|
VS-V5540IR-IP
|
VS-V5552IR-IP
|
VS-V5580IR-IP
|
||
Sensor
|
1/3" CMOS sensor
|
1/2.8" CMOS sensor
|
1/2.7" CMOS sensor
|
||
Video compression
|
H.265AI (Compatible with H.265/H.264),
support dual stream, AVI;
0.1M~8Mpbs variable, 1~30f/s variable
|
|
|
||
Image output
|
Main stream: 2560*1440@25fps, 2304*1296@25fps, 1920*1080@25fps;
sub-stream:
800*448@25fps
|
Main stream:
2592*1944@25fps,
2560*1440@25fps,
2304*1296@25fps,
1920*1080@25fps;
sub-stream:
800*448@25fps
|
Main stream:
8MP: 3840*2160@15fps
5MP: 2880*1616@25fps
4MP: 2560*1440@25fps
2MP: 1920*1080@25fps
sub-stream:
800*448@25fps
|
||
Shutter
|
1/50(1/60)s to 1/10,000s
|
|
|
||
Lens
|
HD Board lens 3.6mm
|
|
|
||
Infrared Leds
|
15pcs IR Leds
|
|
|
||
Illuminate Distance
|
15-20Meters
|
|
|
||
Day and night
|
Support IR-CUT, day and night auto switch
|
|
|
||
Noise reduction
|
Support 2D/3D
|
|
|
||
Wide dynamic
|
Support digital
|
|
|
||
Intelligence analysis
|
Supporting Face detection, Humanoid detection.
|
|
|
||
Other function
|
Support WEB, OSD, live video transmission, motion detect and IO alarm,
front-end storage / playback / download, and center reminder and image linkage, support JPEG capture, united remote client monitoring software |
|
|
||
Mobile monitoring
|
Support multiple mobile monitoring(iOS,Android )
|
|
|
||
Network interface
|
1*RJ45 10/100M adaptive Ethernet port; support RTSP/FTP/DHCP/NTP/UPnP
|
|
|
||
Power
|
DC12V input, power consumption:≤3W
|
|
|
||
Other
|
Support POE power supply (optional)
|
|
|
||
Dimension
|
110mm(¢) ×83mm(H)
|
|
|
||
Net weight
|
Approx.400g
|
|
|
Packing & Delivery
color box and carton box
