Quick Details
-
Brand Name:
-
yuyang
-
Model Number:
-
N35~N52 circular strong magnetic field
-
Delivery Time:
-
7-21 days
-
Packing:
-
OPP Bag + box
-
MOQ:
-
500 Pieces
-
Size:
-
Customized Magnet Size
-
Coating:
-
znic,nickel, ni-cu-ni and so on
-
Certification:
-
ISO9001,ROHS,REACH
-
Magnetism direction:
-
Customized , Axial, Diameter, and so on
-
Density:
-
7.45g/mm3
-
Working Temperature:
-
80℃~230℃
-
Processing:
-
Sintered
-
Testing:
-
SST: 24~72 hours,HPLC-FLD:ROHS six,Vertical tension
Quick Details
-
Tolerance:
-
±1%, ±0.05mm~±0.1mm
-
Grade:
-
NdFeB, Customized, From N35 to N52NdFeB
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
yuyang
-
Model Number:
-
N35~N52 circular strong magnetic field
-
Delivery Time:
-
7-21 days
-
Packing:
-
OPP Bag + box
-
MOQ:
-
500 Pieces
-
Size:
-
Customized Magnet Size
-
Coating:
-
znic,nickel, ni-cu-ni and so on
-
Certification:
-
ISO9001,ROHS,REACH
-
Magnetism direction:
-
Customized , Axial, Diameter, and so on
-
Density:
-
7.45g/mm3
-
Working Temperature:
-
80℃~230℃
-
Processing:
-
Sintered
-
Testing:
-
SST: 24~72 hours,HPLC-FLD:ROHS six,Vertical tension
Product Description
|
Material
|
Sintered Ndfeb permanent magnet
|
Sintered Ndfeb permanent magnet
|
|
|
Magnetic Coating
|
Ni,Zn,Au,Ag,Epoxy,Passivated,etc
|
|
|
|
Magnet Shape
|
Disc,Cylinder,Block,Ring,Countersunk,Segment,Trapezoid and Irregular shapes and more.Customized shapes are available
|
|
|
|
Features
|
The most powerful permanent magnet, offers a great return for cost & performance, have the highest field/surface strength(Br),
high coercivity(Hc), can be easily formed into various shapes and sizes. Be reactive with moisture and oxygen,usualy supplied by plating (Nickel, Zinc, Passivatation, Epoxy coating, etc.). |
|
|
|
Applications
|
Mechanical, electronic products, communications, motors, horns, sensors, medical and so on
|
|
|
|
Working Temperature
|
Grade
|
Temperature
|
|
|
|
N35~N52
|
≤80℃
|
|
|
|
30M~52M
|
≤100℃
|
|
|
|
28H~50H
|
≤120℃
|
|
|
|
28SH~48SH
|
≤150℃
|
|
|
|
28UH~42UH
|
≤180℃
|
|
|
|
28EH~38EH
|
≤200℃
|
|
|
|
28AH~33AH
|
≤230℃
|
|
Specification
|
item
|
value
|
|
Place of Origin
|
China
|
|
|
Guangdong
|
|
Brand Name
|
yuyang
|
|
Model Number
|
N35~N52
|
|
Type
|
Permanent
|
|
Composite
|
NdFeB Magnet
|
|
Shape
|
Block
|
|
Application
|
Industrial Magnet
|
|
Tolerance
|
±1%,±0.05~±0.1mm
|
|
Processing Service
|
Cutting
|
|
Grade
|
NdFeB
|
|
Delivery Time
|
8-14 days
|
|
Size
|
20*10*5mm,customized size
|
|
Material
|
sintered Ndfeb
|
|
Product Name
|
Square Ndfeb magnet
|
|
Coating
|
znic,nickel, ni-cu-ni and so on
|
|
Certification
|
ISO9001,ROHS,REACH
|
|
Magnetism direction
|
Customized , Axial, Diameter, and so on
|
|
Density
|
7.45g/mm3
|
|
Working temperature
|
80-220 Degree Centigrade
|
|
Free sample
|
yes
|
|
Package
|
OPP Bag + box
|
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
