60L/H 40Mpa high pressure homogenizer milk juice homogenizer
60L/H 40Mpa high pressure homogenizer milk juice homogenizer
60L/H 40Mpa high pressure homogenizer milk juice homogenizer
60L/H 40Mpa high pressure homogenizer milk juice homogenizer
60L/H 40Mpa high pressure homogenizer milk juice homogenizer
60L/H 40Mpa high pressure homogenizer milk juice homogenizer
60L/H 40Mpa high pressure homogenizer milk juice homogenizer
60L/H 40Mpa high pressure homogenizer milk juice homogenizer

60L/H 40Mpa high pressure homogenizer milk juice homogenizer

FOB Reference Price: Get Latest Price
≥2 Pieces
US $3200
≥5 Pieces
US $3100
≥10 Pieces
US $3000
≥50 Pieces
US $2900
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Model Number:
HPH-6060
Voltage:
220V, 380V
Power:
2.2kw
Weight:
220 KG
Dimension(L*W*H):
700x350x1000
Flow rate:
60LPH
Max pressure:
40Mpa
Rated pressure:
36Mpa
Contact part:
SS304
motor power:
2.2kw
Certification:
CE
Application scope:
liquid product like juice milk ice cream

Quick Details

Marketing Type:
fast delivery
Place of Origin:
Zhejiang, China
Brand Name:
Ranking
Model Number:
HPH-6060
Voltage:
220V, 380V
Power:
2.2kw
Weight:
220 KG
Dimension(L*W*H):
700x350x1000
Flow rate:
60LPH
Max pressure:
40Mpa
Rated pressure:
36Mpa
Contact part:
SS304
motor power:
2.2kw
Certification:
CE
Application scope:
liquid product like juice milk ice cream
Description

High pressure homogenizer

High-Pressure Homogenization

High-pressure homogenizers are most commonly used for creating emulsions and for cell lysis when relatively large volumes are being processed. These are also the kinds of homogenizers used in the dairy industry, albeit on a larger scale.

Specification

High pressure homogenize specification

here below are the main specifications of our HPH-60 series high pressure homogenizer

Model
HPH-6040
HPH-6060
HPH-6070
HPH-60100
Flowrate
60L/H
60L/H
60L/H
60L/H
Max working pressure
40MPa
60Mpa
70MPa
100MPa
Working pressure
0~36Mpa
0~48Mpa
0~56Mpa
0~80Mpa
Motor power
2.2kw
3kw
3kw
4kw
Dimension
70x35x100cm
70x35x100cm
70x35x100cm
70x70x100cm
Weight
220kg
220kg
220kg
240kg
Minimum experimental quantity
300ml
300ml
300ml
300ml
Max working temp.
100℃
100℃
100℃
100℃
Max viscosity
200cps
200cps
200cps
200cps
How to work

How does a high pressure homogenizer work

High-pressure homogenizers consist of a tank to which high pressure is applied in order to force the liquid sample contained therein through a valve or membrane with very narrow slits. This act causes high shear, a large pressure drop, and cavitation, all of which act to homogenize the sample. High-pressure homogenizers are most commonly used for creating emulsions and for cell lysis when relatively large volumes are being processed.

Price

High pressure homogenizer price

we have some different model and pressure range high pressure homogenizer for you. due to the raw material and exchange rate keep changing, the prices list in this site may not exactly correct. Please drop us a line for to get the latest price.
