Quick Details
-
Fork Length:
-
1070-1500mm
-
Fork Width:
-
160-180mm
-
Weight (KG):
-
12860 kg
-
Rated capacity:
-
15000 KG
-
Lift height:
-
3000 MM
-
Service weight:
-
12860 KG
-
Fork size:
-
1500/160/75 MM
-
Front overhang:
-
733mm
-
Length to fork facea:
-
4258mm
-
Overall width:
-
2245mm
-
Mast lowered heightdimension:
-
2845mm
-
Mast extended height:
-
4307mm
-
Overhead guard height:
-
2565mm
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Neolift
-
Fork Length:
-
1070-1500mm
-
Fork Width:
-
160-180mm
-
Weight (KG):
-
12860 kg
-
Rated capacity:
-
15000 KG
-
Lift height:
-
3000 MM
-
Service weight:
-
12860 KG
-
Fork size:
-
1500/160/75 MM
-
Front overhang:
-
733mm
-
Length to fork facea:
-
4258mm
-
Overall width:
-
2245mm
-
Mast lowered heightdimension:
-
2845mm
-
Mast extended height:
-
4307mm
-
Overhead guard height:
-
2565mm
Products Specification
|
Model
|
FD1.0-1.8T
|
FD2.0-3.5T
|
FD4.0-5T
|
FD5.0-7T
|
FD8.0-10T
|
|
Power type
|
Diesel
|
Diesel
|
Diesel
|
Diesel
|
Diesel
|
|
Load center
|
500MM
|
500MM
|
500MM
|
500MM
|
500MM
|
|
Liftheight
|
3000MM
|
3000MM
|
3000MM
|
3000MM
|
3000MM
|
|
Free lift height
|
162MM
|
140/145MM
|
150/155MM
|
205-215MM
|
205/210MM
|
|
Fork size
|
920*100*40MM
|
1070*120*40MM
|
1070*140*50MM
|
1200*150*55MM
|
1500*160*75MM
|
|
Mast tilt angle
|
6\12
|
6\12
|
6\12
|
6\12
|
6\12
|
|
Front overhang
|
429MM
|
484-500MM
|
562/567MM
|
622-632MM
|
700/733MM
|
|
Mast extended height
|
4042MM
|
4070-4272MM
|
4275MM
|
4429MM
|
4445/4307MM
|
|
Overhead guard height
|
2075MM
|
2060-2090MM
|
2250MM
|
2420MM
|
2565MM
|
|
Max. grade ability
|
20%
|
15-20%
|
≥20%
|
≥20%
|
20%
|
