Quick Details
-
Model Number:
-
GT5000
-
Place of Origin:
-
China
-
CPU:
-
Intel Core i5 4200U
-
Storage::
-
Max 8gb RAM, support 1 mSATA SSD+1 2.5" SATA
-
Ports::
-
6*COM.1*HD, 1*LPT,2*Gigabit Lan, 4* USB 3.0, 4*USB2.0,1DC
-
Graphics::
-
Intel HD Graphics
-
Case::
-
Brushed Alloy Case
-
RAM:
-
DDR3L 2GB/4GB/8GB Optional
-
Feature1::
-
Fanless System 0.00dB
-
Features2:
-
Support watch dog.PXE booting.Wake-on-Lan
-
Size:
-
230*175*50mm
-
Weight:
-
2.5KG
Quick Details
-
Screen Size:
-
No Monitor
-
Processor Main Frequency:
-
1.6GHz-2.6GHz
-
Brand Name:
-
JIERUICC
-
Model Number:
-
GT5000
-
Place of Origin:
-
China
-
CPU:
-
Intel Core i5 4200U
-
Storage::
-
Max 8gb RAM, support 1 mSATA SSD+1 2.5" SATA
-
Ports::
-
6*COM.1*HD, 1*LPT,2*Gigabit Lan, 4* USB 3.0, 4*USB2.0,1DC
-
Graphics::
-
Intel HD Graphics
-
Case::
-
Brushed Alloy Case
-
RAM:
-
DDR3L 2GB/4GB/8GB Optional
-
Feature1::
-
Fanless System 0.00dB
-
Features2:
-
Support watch dog.PXE booting.Wake-on-Lan
-
Size:
-
230*175*50mm
-
Weight:
-
2.5KG
Please noted this link is for GT5000 with Core i5-4200U Barbone with Wifi Only, Don't include RAM/SSD/HDD etc...
If you need other configuration,please contact us directly
Contact Greenthinpc Technology ASAP
1. Dual Intel Gigabit LAN ,8USB port. 4*USB3.0,4*USB2.0
2. 6 COM port. COM 1&COM 2 Support RS232 RS422 RS485 switch from BIOS setting,no need to open the device.
3. 8Bit GPIO support various user different requirements
4. Special LPT print port.
5. HD+VGA dual display
6. Half height pcie support Wifi . Full height support 4G
7. Embedded with SIM card slot
8. Support Wake-on-Lan / PXE / 256 Watchdog
9. Industrial grade mini pc. 7*24hours working
| General | |
| CPU |
1. Intel Core i5 4200U (3M Cache, 1.6-2.6GHz) 4 core 4 threads, Intel HD 4400 Graphics,DDR3L RAM
2. Intel Core i7 4500U (4M Cache, 1.8-3.0GHz) 2 core 4 threads, Intel HD 4400 Graphics,DDR3L RAM |
| Core (FSB) | 100MHz |
| CPU Technique | 22nm |
| L1 Cache | 2 x 32 KB, 8-Way, 64 byte lines |
| L2 Cache | 2 x 256 KB, 8-Way, 64 byte lines |
| L3 Cache | 3 MB, 12-Way, 64 byte lines |
|
MMX, SSE, SSE2, SSE3, SSSE3, SSE4.1, SSE4.2, HTT, EM64T, EIST, Turbo Boost |
|
| Motherboard | Intel CRESCENTBAY ( Lynx Point-LP ) |
| BOIS | American Megatrends Inc. 5.6.5 |
| Chipset | Intel Haswell |
| Memory | 1* SO-DIMM DDR3L Slot |
| Support 4GB/8GB (Optional) | |
| DDR3L 1333/1600, LPDDR3 1333/1600 | |
| Storage | 1*MSATA SSD: 8G/16G/32G/64G/128G/256G/512G/1TB (Optional) |
| 1*SATA HDD: 160G/320G/500G/1TB (Optional) | |
| Operating System | Win7/Win8/Win10/Linux |
| Audio | ALC662 HD Audio(Line-in, Line-out, Mic-in) |
| Intel Lynx Point-LP HD Audio Controller | |
| Network | Onboard Intel i211 Gigabit Network Connection |
| 10/100Mbps/1000Mbps BaseT LAN | |
| Video | Intel Haswell- ULT Integrated Graphics Controller |
| Intel HD Graphics 4400 | |
| I/O port | |
| front panel ports | 2*USB3.0, 2*USB2.0, 1* Switch, 6*RS232 COM |
| Backside ports |
2*USB3.0, 2*USB2.0, 1*HDMI, 1*VGA, 2*LAN, 1*GPIO, 1*LPT, 1*MIC, 1*SPK, 1*DC IN, 2*Wi-Fi |
| COM | 6*RS232(3 line), COM1 COM2 support set to RS458/RS422 |
| Internal ports | 1*M-SATA3.0 port, support 6Gb/s |
| 1*SATA3.0 port, support 6Gb/s | |
| 1*mini PCIE-half(Pcie bus) port for WiFi module | |
| 1*mini PCIE-full(Usb bus) port for 4G module | |
| SIM slot | Micro SIM, with PUSH function |
| Power and Working Environment | |
| Input | DC100-240V AC/50-60Hz |
| Output | 12V/5A |
| Operating Temperature | -20/+75 Centigrade |
| Storage Temperature | -40/+80 Centigrade |
| Relative Humidity | 0%~90% (non-condensing) |
| Product Dimension & Details | |
| Size | 230*175*50mm |
| Weight | 2.5KG |
| Consumption | 15W |
| Shell | Black |
| Package Content | 1x Mini PC |
| 1x Power Adapter (Correct plug shipped based on buyer's country) | |
| 1x WiFi Module with antennas | |
| 1x SATA cables | |
Industrial PC Application Area
Finance retail,Advertising machine,Audio Player/Server,Electronic map machine,All-in-One PC,POS cash register,Interactive ordering machine in restaurant,Intelligent transportation,Digital signage,Education IWB(Interactive Whiteboard),Conference electronic whiteboard,Industrial PC,Subway/Metro/MRT/Tube/automatically Entrance&Export gate,Face recognition turnstile gate,Industrial camera,Data collection,Video capture,Automatic welding machine,Industrial robot,Bank ATM and other fields.
