Quick Details
-
Model Number:
-
Rubber Hose
-
Material:
-
Nature Rubber, NR,NBR
-
Inner Diameter:
-
300-1600mm or as request
-
Working pressure:
-
6-25 bar or as request
-
Wall Thickness:
-
75-90mm or as request
-
Cover Rubber:
-
Nature Rubber, NR,NBR, CR or as request
-
Reinforcement layer:
-
High tensile textile with helix steel wire
-
Reinforcement:
-
Sprial Steel Wire
-
Working temperature:
-
-20℃ ~ 80℃
-
Safe Factor:
-
3:1 or as request
-
Hose length:
-
5.8m, 11.8m or as request
Quick Details
-
Processing Service:
-
Moulding, Cutting
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
Olive
-
Model Number:
-
Rubber Hose
-
Material:
-
Nature Rubber, NR,NBR
-
Inner Diameter:
-
300-1600mm or as request
-
Working pressure:
-
6-25 bar or as request
-
Wall Thickness:
-
75-90mm or as request
-
Cover Rubber:
-
Nature Rubber, NR,NBR, CR or as request
-
Reinforcement layer:
-
High tensile textile with helix steel wire
-
Reinforcement:
-
Sprial Steel Wire
-
Working temperature:
-
-20℃ ~ 80℃
-
Safe Factor:
-
3:1 or as request
-
Hose length:
-
5.8m, 11.8m or as request
Products Description
competitive price rubber material 8 10 12 inch slurry reinforced suction hose
|
Tube
|
NR, BR, SBR
|
|
Reinforcement
|
High tensile strength fabrics
|
|
Cover
|
NR, CR
|
|
Ideal Working Temperature
|
-20℃ to 80℃
|
|
Safety Factor
|
3:1
|
|
Application
|
Used for port, dock, discharge sea water, silt, sand, flood, etc. Particularly suited to the work of dredging construction for dock and port, Building Project and so on.The suction hose has good stiffness,can not be abnormal abrasion,the arch and eddy of some part place of inner rubber that is formed by the bend of the storm and tide.
|
|
Advantages
|
High Abrasion Resistance
|
|
|
Light Weight
|
|
|
Oil and Heat Resistant
|
|
|
Flexible,easy to bending
|
|
I.D.
|
|
W.P.
|
B.P.
|
Length
|
Pipe Wall Thickness
|
|||||
|
mm
|
tolerance/mm
|
bar
|
bar
|
m
|
mm
|
|||||
|
300
|
±2
|
4~12
|
36
|
1~3
|
34~37
|
|||||
|
450
|
±2
|
4~12
|
36
|
1~3
|
35~37
|
|||||
|
560
|
±3
|
4~12
|
36
|
2~3
|
40~45
|
|||||
|
600
|
±3
|
4~12
|
36
|
2~3
|
40~45
|
|||||
|
700
|
±3
|
8~15
|
45
|
2~3
|
40~45
|
|||||
|
800
|
±4
|
12~25
|
55
|
2~3
|
50~52
|
|||||
|
900
|
±4
|
15~25
|
75
|
2~3
|
55~58
|
|||||
|
1000
|
±5
|
20~25
|
75
|
3~5
|
75
|
|||||
|
1100
|
±5
|
25~30
|
80
|
3~5
|
90
|
|||||
|
NOTE: Other parameters are by your requirements.
|
|
|
|
|
|
|||||
