Quick Details
-
Panel Efficiency:
-
22.5%
-
Product name:
-
Jiasheng 144 half cell high efficiency solar panel
-
Solar cell:
-
mono 144 half Cell
-
Frame:
-
Anodized Aluminium Alloy
-
Weight:
-
25.7kg
-
Cell Type:
-
Mono PERC 166*166mm
-
Efficiency:
-
22.5%
-
Brand:
-
Gain solar
-
Keyword:
-
Pv Solar Panel
-
Packing:
-
31pcs/ctn
-
OEM/ODM:
-
Highly Welcomed
-
Size:
-
2256mm / 1133mm / 35mm
-
Certificate:
-
TUV,CE, CCC, ISO
-
Warranty:
-
12YEARS
Quick Details
-
Brand Name:
-
Gain Solar
-
Model Number:
-
YL540DL72 -J210804
-
Place of Origin:
-
Hebei, China
-
Panel Efficiency:
-
22.5%
-
Product name:
-
Jiasheng 144 half cell high efficiency solar panel
-
Solar cell:
-
mono 144 half Cell
-
Frame:
-
Anodized Aluminium Alloy
-
Weight:
-
25.7kg
-
Cell Type:
-
Mono PERC 166*166mm
-
Efficiency:
-
22.5%
-
Brand:
-
Gain solar
-
Keyword:
-
Pv Solar Panel
-
Packing:
-
31pcs/ctn
-
OEM/ODM:
-
Highly Welcomed
-
Size:
-
2256mm / 1133mm / 35mm
-
Certificate:
-
TUV,CE, CCC, ISO
-
Warranty:
-
12YEARS
Recommend Products
Products Description
|
Place of Origin:Hebei, China
|
Brand Name:Gain Solar/ Yingli Solar
|
|
Model Number:YLxxxD-49e 1/2 (xxx=Pmax)
YLXXXD-49e 1500V 1/2(XXX=Pmax)
|
Type:PERC, Half Cell, Bifacial
|
|
Size: 2256×1133×35 mm
|
Panel Efficiency: 20.3 %-21.1%
|
|
Certificate:TUV/CE,TUV/IEC61215/IEC61730/ISO
|
Warranty: 25 years Linner Warranty
|
|
Solar cell: mono 144 half Cell
|
Junction Box:IP67 Rated
|
|
Frame: Anodized Aluminium Alloy
|
Frame Color:Frame Color
|
|
Backsheet: Black and White
|
Front Glass: Temperd Glass
|
|
Connector: MC4
|
Cable: PV 4mm2
|
|
Cable:PV cable 4mm2 with MC4 Connector
|
OEM Order:Acceptable
|
|
YLxxxD-29b(1500v)(xxx=Pmax)
|
|
|
|
|
|
|
|
|
||||||||
|
|
525（W）
|
|
530
|
|
535
|
|
540
|
|
||||||||
|
|
STC
|
NOCT
|
STC
|
NOCT
|
STC
|
NOCT
|
STC
|
NOCT
|
||||||||
|
Power output
|
525
|
390.6
|
530
|
394.3
|
535
|
398
|
540
|
401.8
|
||||||||
|
Voltage at Pmax
|
41.25
|
38.4
|
41.4
|
38.5
|
41.55
|
38.6
|
41.7
|
38.8
|
||||||||
|
Current at Pmax
|
12.73
|
10.18
|
12.81
|
10.28
|
122.88
|
10.3
|
12.95
|
10.36
|
||||||||
|
Open-circuit voltage
|
49.07
|
46
|
49.22
|
46.1
|
49.37
|
46.2
|
49.52
|
46.4
|
||||||||
|
Short-circuit current
|
13.62
|
11
|
13.69
|
11.06
|
13.76
|
11.12
|
13.83
|
11.17
|
||||||||
|
Power Tolerance(W)
|
0-5W
|
|
|
|
|
|
|
|
||||||||
|
Max. system voltage
|
1000VDC/1500VDC
|
|
|
|
|
|
|
|
||||||||
|
Max. series fuse rating*
|
20A
|
|
|
|
|
|
|
|
||||||||
Company Strength
Certifications
Up to now, our company's BIPV and solar modules have obtained lots of certification, such as:
☑
CE
:CONFORMITE EUROPEENNE
☑ ISO9001, ISO14001, ISO45001
☑ CCC : China Compulsory Certification
☑ TUV :TUV Rheinland.
☑ CGC :China General certification.etc.
☑ ISO9001, ISO14001, ISO45001
☑ CCC : China Compulsory Certification
☑ TUV :TUV Rheinland.
☑ CGC :China General certification.etc.
