Quick Details
-
Output:
-
24V 5A
-
Input:
-
100-240V, 50/60Hz
-
Output power:
-
120W
-
DC plug:
-
5.5*2.1mm, 5.5*2.5mm or others
-
Dimension:
-
135*50*32mm
-
DC cable length:
-
1m, 1.2m, 1.5m, 1.8m, 2m, 2.5m, 3m
-
Protection:
-
Over current,Over voltage,Short circuit
-
Weight:
-
420g
-
Warranty:
-
2 years
Quick Details
-
Output Type:
-
DC
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
TDX
-
Output:
-
24V 5A
-
Input:
-
100-240V, 50/60Hz
-
Output power:
-
120W
-
DC plug:
-
5.5*2.1mm, 5.5*2.5mm or others
-
Dimension:
-
135*50*32mm
-
DC cable length:
-
1m, 1.2m, 1.5m, 1.8m, 2m, 2.5m, 3m
-
Protection:
-
Over current,Over voltage,Short circuit
-
Weight:
-
420g
-
Warranty:
-
2 years
PRODUCT DESCRIPTION
1.Over-Voltage protection
2.Over-Current protection
3.Short-Circuit protection
4.100% Hi-pot&ATE(Chroma) Tested
5.100% Burn-in under High
6.Ambient Temperature(40°C)
7.Low Ripple/Noise
8.MTBF Above 40000 HRS AT 25C
9LVD authentication
10. Limited power sources(LPS)
11.CEC IV and V Efficiency
12. Cispr22 CLASS B FCC Part 15 CLASS B
|
Voltage Range
|
100~240V AC
|
|
Frequency Range
|
50/60HZ
|
|
Efficiency
|
85% min
|
|
Output Voltage
|
5V 9V 12V 15V 16V 18V 20V 24V 32V 36V 42V 48V
|
|
Output Current
|
1A 1.5A 2A 2.5A 3A 4A 5A 6A 7A 8A 9A 10A 12A
|
|
Voltage Tolerance
|
±5%
|
|
Storange Temp., Humidity
|
-20~+85℃, 10~95%RH
|
|
Working Temp
|
-10~+65℃
|
|
Working Humidity
|
20~90% RH non-condensing
|
Established in 2009,Shenzhen Teng Da Xing Electron Co., Ltd is a professional manufacturer of power adapter as well as an integrated enterprise of R&D, mass production, sales and after sales in Shenzhen, China.
Our wide range of power adapter cover from 5W-300W according to the requirements of customization from customers. All the products are 100% Burn-in test and have passed UL, CE, FCC, ROHS,PSE, SAA, ETL, CB, KC, BIS, UKCA, GS, RCM, C-Tick etc.
OEM and ODM orders are always highly welcomed.We have dedicated teams of R&D and quality control focusing on products quality guarantee. In addition, the strong production capacities allow fast lead-time and guarantee fresh & premium products at competitive prices.
“Quality first, customer foremost” is our unchangeable service tenet. With over 15 years of experience in exporting, we win high reputation from domestic and foreign clients as satisfied quality and service,
So trust us, make your wise decision today!
OUR EXHIBITION
OUR CERTIFICATE
PRODUCT APPLICATION
DC CONNECTORS
AC PLUGS
FAQ
1.What is vour MOQ?
Our MOQ is 500pcs,We can supply 100pcs in your first order.
2.What is your superiority?
Only 2% Issue complaints rate , And accept DDP price item for north America,Europe ,Australia.
3.Can you accept free samples?
We can supply 1-2pcs free samples,Customer need to pay for freight.
4 How long the warranty ?
2 years.
5.Are you factory?and where is located in?
Yes, we're factory and we're located in Shenzhen.
6.Can you accept credit card or alibaba payment?
Yes,we accept credit card or alibaba payment.
