Quick Details
-
Weight:
-
76.5g
-
Selling Units:
-
Single item
-
Single package size:
-
12X12X12 cm
-
Single gross weight:
-
0.3 kg
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ANG
-
Model Number:
-
Brotherhobby, Avenger 2812 V3
-
Weight:
-
76.5g
-
Selling Units:
-
Single item
-
Single package size:
-
12X12X12 cm
-
Single gross weight:
-
0.3 kg
Key attributes
Industry-specific attributes
Type
agriculture use
Function
Multi-rotor Quadcopter UAV
Other attributes
Place of Origin
Guangdong, China
Brand Name
BrotherHobby
Model Number
2812 V3 900KV/1115KV-5-8S
Material
Plastic
Power
motor
Private Mold
NO
Capacity
1 ml
KV:
900KV/1115KV
Configuration:
12N14P
No.of Cells(Lipo):
4-6S
Rotor:
N52H arc magnets
Stator:
0.2mm Kawasaki silicon steel
Shaft:
Titanium Alloy hollow shaft
Bearings:
Japanese NMB 12x6x4 mm
Bell cap: Al 7075 Base casing:
Al 7075
Wire AWG:
18AWG 25cm length
Prop Adapter Shaft Thread:
M5
Packaging and delivery
Packaging Details
box
Port
ShenZhen
Supply Ability
Supply Ability
10000 Box/Boxes per Month
Lead time
| Quantity (bags) | 1 - 1 | > 1 |
| Lead time (days) | 7 | To be negotiated |
Overview
Features
Features
Brotherhobby Avenger 2812 V3 900KV/1115KV Brushless Motor 5-8S Titanium Alloy hollow shaft 9047 Propeller Quadcopter FPV Racing Drones KV: 900KV
Configuration: 12N14P
No.of Cells(Lipo): 4-6S
Rotor: N52H arc magnets
Stator: 0.2mm Kawasaki silicon steel
Shaft: Titanium Alloy hollow shaft
Bearings: Japanese NMB 12x6x4 mm
Wire AWG: 18AWG 25cm length
Bell cap: Al 7075 Base casing: Al 7075
Prop Adapter Shaft Thread: M5
Bolt Pattern: M3 (19X19mm)
Weight: 76.5g with 25cm SR wires
900kv: CF9*4.7 6S 40A
Item Packing
Motor x1
M2 Screw x4
M5 Nut x1
Configuration: 12N14P
No.of Cells(Lipo): 4-6S
Rotor: N52H arc magnets
Stator: 0.2mm Kawasaki silicon steel
Shaft: Titanium Alloy hollow shaft
Bearings: Japanese NMB 12x6x4 mm
Wire AWG: 18AWG 25cm length
Bell cap: Al 7075 Base casing: Al 7075
Prop Adapter Shaft Thread: M5
Bolt Pattern: M3 (19X19mm)
Weight: 76.5g with 25cm SR wires
900kv: CF9*4.7 6S 40A
Item Packing
Motor x1
M2 Screw x4
M5 Nut x1
