Quick Details
-
Ports:
-
48
-
Brand Name:
-
S5331-S48S4X-D
-
Model Number:
-
S5331-S48S4X-D
-
Place of Origin:
-
Guangdong, China
Quick Details
-
Transmission Rate:
-
10/100/1000Mbps
-
Communication Mode:
-
Full-Duplex & Half-Duplex
-
Switch Capacity:
-
336 Gbps
-
Ports:
-
48
-
Brand Name:
-
S5331-S48S4X-D
-
Model Number:
-
S5331-S48S4X-D
-
Place of Origin:
-
Guangdong, China
Product Description
CloudEngine S5331-S Series Switches
| CloudEngine S5331-S48S4X-D |
48 x GE SFP ports, 4 x 10GE SFP+ ports
DC power supply Forwarding performance: 125 Mpps Switching capacity: 336 Gbps |
CloudEngine S5331-S series switches are next-generation standard gigabit switches that provide GE electrical/optical downlink ports and 10GE uplink ports.
Product Overview
The CloudEngine S5331-S series switches are based on next-generation high-performing hardware and the Versatile Routing Platform (VRP). The CloudEngine S5331-S supports simplified operations and maintenance (O&M), intelligent stack (iStack), flexible Ethernet networking. It also provides enhanced Layer 3 features and mature IPv6 features. The CloudEngine S5331-S can be used in various scenarios. For example, it can be used as an access or aggregation switch on a campus network or Metropolitan Area Network.
Models
| Models and Appearances | Description |
| CloudEngine S5331-S32ST4X |
24 x GE SFP port,8 x 10/100/1000Base-T Ethernet ports, 4 x 10GE SFP+ ports
1+1 power backup Forwarding performance: 108 Mpps Switching capacity: 336 Gbps |
| CloudEngine S5331-S32ST4X-A |
24 x GE SFP port,8 x 10/100/1000Base-T Ethernet ports, 4 x 10GE SFP+ ports
AC power supply Forwarding performance: 108 Mpps Switching capacity: 336 Gbps |
| CloudEngine S5331-S32ST4X-D |
24 x GE SFP port,8 x 10/100/1000Base-T Ethernet ports, 4 x 10GE SFP+ ports
DC power supply Forwarding performance: 108 Mpps Switching capacity: 336 Gbps |
| CloudEngine S5331-S24S8T4X-A |
24 x GE SFP port,8 x 10/100/1000Base-T Ethernet ports, 4 x 10GE SFP+ ports*
AC power supply Forwarding performance: 108 Mpps Switching capacity: 336 Gbps Note: GE0/0/1 to GE0/0/24 are SFP ports |
| CloudEngine S5331-S24S8T4X-D |
24 x GE SFP port,8 x 10/100/1000Base-T Ethernet ports, 4 x 10GE SFP+ ports*
DC power supply Forwarding performance: 108 Mpps Switching capacity: 336 Gbps Note: GE0/0/1 to GE0/0/24 are SFP ports |
| CloudEngine S5331-S48S4X |
48 x GE SFP ports, 4 x 10GE SFP+ ports
1+1 power backup Forwarding performance: 125 Mpps Switching capacity: 336 Gbps |
| CloudEngine S5331-S48S4X-A |
48 x GE SFP ports, 4 x 10GE SFP+ ports
AC power supply Forwarding performance: 125 Mpps Switching capacity: 336 Gbps |
| CloudEngine S5331-S48S4X-D |
48 x GE SFP ports, 4 x 10GE SFP+ ports
DC power supply Forwarding performance: 125 Mpps Switching capacity: 336 Gbps |
| CloudEngine S5331-S24T4X |
24 x 10/100/1000Base-T Ethernet ports, 4 x 10GE SFP+ ports
1+1 power backup Forwarding performance: 96 Mpps Switching capacity: 336 Gbps |
| CloudEngine S5331-S24T4X-A |
24 x 10/100/1000Base-T Ethernet ports, 4 x 10GE SFP+ ports
AC power supply Forwarding performance: 96 Mpps Switching capacity: 336 Gbps |
| CloudEngine S5331-S24T4X-D |
24 x 10/100/1000Base-T Ethernet ports, 4 x 10GE SFP+ ports
DC power supply Forwarding performance: 96 Mpps Switching capacity: 336 Gbps |
| CloudEngine S5331-S24P4X |
24 x 10/100/1000Base-T Ethernet ports, 4 x 10GE SFP+ ports
1+1 power backup PoE+ Forwarding performance: 96 Mpps Switching capacity: 336 Gbps |
| CloudEngine S5331-S48T4X |
48 x 10/100/1000Base-T Ethernet ports, 4 x 10GE SFP+ ports
1+1 power backup Forwarding performance: 125 Mpps Switching capacity: 336 Gbps |
| CloudEngine S5331-S48T4X-A |
48 x 10/100/1000Base-T Ethernet ports, 4 x 10GE SFP+ ports
AC power supply Forwarding performance: 125 Mpps Switching capacity: 336 Gbps |
| CloudEngine S5331-S48P4X |
48 x 10/100/1000Base-T Ethernet ports, 4 x 10GE SFP+ ports
1+1 power backup PoE+ Forwarding performance: 125 Mpps Switching capacity: 336 Gbps |
Ordering Information
| Model | Product Description |
| CloudEngine S5331-S32ST4X | CloudEngine S5331-S32ST4X(8*10/100/1000BASE-T ports, 24*GE SFP ports, 4*10GE SFP+ ports, without power module) |
| CloudEngine S5331-S32ST4X-A | CloudEngine S5331-S32ST4X-A(8*10/100/1000BASE-T ports, 24*GE SFP ports, 4*10GE SFP+ ports, AC power, front access) |
| CloudEngine S5331-S32ST4X-D | CloudEngine S5331-S32ST4X-D(8*10/100/1000BASE-T ports, 24*GE SFP ports, 4*10GE SFP+ ports, DC power, front access) |
| CloudEngine S5331-S24S8T4X-A | CloudEngine S5331-S24S8T4X-A(24*GE SFP ports, 8*10/100/1000BASE-T ports, 4*10GE SFP+ ports, AC power, front access) |
| CloudEngine S5331-S24S8T4X-D | CloudEngine S5331-S24S8T4X-D(24*GE SFP ports, 8*10/100/1000BASE-T ports, 4*10GE SFP+ ports, DC power, front access) |
| CloudEngine S5331-S48S4X | CloudEngine S5331-S48S4X(48*GE SFP ports, 4*10GE SFP+ ports, without power module) |
| CloudEngine S5331-S48S4X-A | CloudEngine S5331-S48S4X-A(48*GE SFP ports, 4*10GE SFP+ ports, AC power, front access) |
| CloudEngine S5331-S48S4X-D | CloudEngine S5331-S48S4X-D(48*GE SFP ports, 4*10GE SFP+ ports, DC power, front access) |
| CloudEngine S5331-S24T4X | CloudEngine S5331-S24T4X (24*10/100/1000BASE-T ports, 4*10GE SFP+ ports, without power module) |
| CloudEngine S5331-S24T4X-A | CloudEngine S5331-S24T4X-A (24*10/100/1000BASE-T ports, 4*10GE SFP+ ports, AC power) |
| CloudEngine S5331-S24T4X-D | CloudEngine S5331-S24T4X-D (24*10/100/1000BASE-T ports, 4*10GE SFP+ ports, DC power) |
| CloudEngine S5331-S24P4X | CloudEngine S5331-S24P4X (24*10/100/1000BASE-T (PoE+) ports, 4*10GE SFP+ ports, without power module) |
| CloudEngine S5331-S48T4X | CloudEngine S5331-S48T4X (48*10/100/1000BASE-T ports, 4*10GE SFP+ ports, without power module) |
| CloudEngine S5331-S48T4X-A | CloudEngine S5331-S48T4X-A (48*10/100/1000BASE-T ports, 4*10GE SFP+ ports, AC power) |
| CloudEngine S5331-S48P4X | CloudEngine S5331-S48P4X (48*10/100/1000BASE-T (PoE+) ports, 4*10GE SFP+ ports, without power module) |
| PAC150S12-R | 150 W AC power module |
| PDC180S12-CR | 180 W DC power module |
| PAC1000S56-CB | 1000 W AC PoE power module |
| PDC1000S56-CB | 1000 W DC PoE power module |
| S53S-M-Lic | S53XX-S Series Basic SW,Per Device |
