1. Rigorous quality control meeting the highest international standards
2. High-transmissivity low-iron tempered glass, strong aluminium frame Using UV-resistant silicon
3. Aesthetic appearance with excellent efficiency based on innovative photovoltalic technologies
4. High quality,strong aluminium frame,passing mechanical load testing 5400 Pa and wind pressure 2400Pa
Explore More Products
- Product Details
- {{item.text}}
Quick Details
-
Controller Type:
-
MPPT
-
Mounting Type:
-
Roof Mounting
-
Certificate:
-
CE
-
Warranty:
-
2years
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
CINCO
-
Model Number:
-
Off grid-1KW
-
Load Power (W):
-
1kw
-
Output Voltage (V):
-
220v
-
Output Frequency:
-
50hz
-
Work Time (h):
-
8-24 HOURS
-
Specification:
-
Normal
Quick Details
-
Application:
-
Home
-
Solar Panel Type:
-
Monocrystalline Silicon, Polycrystalline Silicon
-
Battery Type:
-
Lead-Acid, Lithium Ion
-
Controller Type:
-
MPPT
-
Mounting Type:
-
Roof Mounting
-
Certificate:
-
CE
-
Warranty:
-
2years
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
CINCO
-
Model Number:
-
Off grid-1KW
-
Load Power (W):
-
1kw
-
Output Voltage (V):
-
220v
-
Output Frequency:
-
50hz
-
Work Time (h):
-
8-24 HOURS
-
Specification:
-
Normal
Products Description
High Quality Solar Panel
Mono crystalline
Poly crystalline
Tracer-AN series MPPT solar controller
1. MPPT tracking efficiency above 99.5%
2. Maximum charge conversion efficiency as high as 98%
3. Support lead-acid and lithium-ion batteries
4. Multiple load work modes
5. Charging power and current limitation function
6. High-temperature charging power derating function
7. Standard Modbus communication protocol with RS485 interface
8. Real-time energy statistics function
High Frequency
Pure Sine Wave Inverter
1. Pure sine wave output
2. Input to output electrical isolation
3. Output power factor up to 1
4. Input Protection: Low-voltage, Over-voltage
5. Output Protection: Overload, Short circuit, Overheating
6. RS485 com. port to realize remote monitoring
7. External switch design, matched with EPEVER products, to expand inverter control function and reduce power consumption
8. Diversified AC output sockets
9. EN/IEC62109-1/2, EN61000-6-2/4, and FCC approved
1. High corrosion resistant performance: Pb-Ca multi-alloy grid
2. High energy density and power density
3. Optimized Capability of instant High-current Discharging
4. Excellent charge acceptance ability
5. Excellent deep cycle discharge capability
6. Strong high and low temperature performance
7. Precision sealing technology
8. Long life
Mounting System
1. Quick assembly numerous pre-assembled parts to reduce assembly times
2. Alternate foundation options include welded plate, concrete pour, ballast, and ground screw.
3. Ultimate flexibility system allows for easy installation of framed and frameless solar modules.
4. The vertical post system vertical adjustability with no cutting or welding.
5. Systems are scalable and repeatable.
6. Solar module orientation portrait or landscape
7. Aluminum alloy frame and stainless steel accessories
Design Solution
|
Item
|
500W
|
1KW
|
1.5KW
|
2KW
|
||||
|
|
160W*2units
36cell Poly
|
160W*4units
36cell Mono |
160W*6units
36cell Mono |
450W*4units
36cell Mono |
||||
|
MPPT Solar Controller
|
12V24V 30A
MPPT solar controller
|
12V24V 30A
MPPT solar controller |
12V24V 40A
MPPT solar controller |
48V 50A
MPPT solar controller |
||||
|
Power Inverter
|
12Vac-120/230Vac
500W Power inverter
|
24Vac-120/230Vac
1000W Power inverter
|
24Vac-120/230Vac
1500W Power inverter
|
48Vac-120/230Vac
2000W Power inverter
|
||||
|
|
12V 55AH*1units
GEL or Lithium Battery
|
12V 100AH*2units
GEL or Lithium Battery |
12V 150AH*2units
GEL or Lithium Battery |
12V 100AH*4units
GEL Battery |
||||
|
|
*1sets
Ground or Roof type
|
*1sets
Ground or Roof type |
*1sets
Ground or Roof type |
*1sets
Ground or Roof type |
||||
|
1. Optional accessories: Combiner box, photovoltaic cable, battery connection cable, battery bracket ect.
2. According to user needs that can be flexibly use 60cell or 72cell monocrystalline polycrystalline solar panels.
|
|
|
|
|
||||
