Quick Details
-
C Content (%):
-
≤0.08
-
Si Content (%):
-
≤1
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
aodeyuan
-
Model Number:
-
stainless steel wire
-
Wire Gauge:
-
0.05mm~4.5mm
-
Surface:
-
bright silver
-
Packing:
-
with box or as your request
-
Varity:
-
hard wire soft wire coil wire spool wire
-
Certification:
-
AISI ASTM DIN EN JIS
-
factory experience:
-
more rhan 10 years
-
Material:
-
stainless steel 300 series
-
Product Name:
-
stainless steel wire rope
-
Product Advantage:
-
High quality Competitive price
-
Sample:
-
Free and available
Quick Details
-
Grade:
-
300 Series
-
Steel Grade:
-
304, 316, 316L
-
Length:
-
as your request
-
C Content (%):
-
≤0.08
-
Si Content (%):
-
≤1
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
aodeyuan
-
Model Number:
-
stainless steel wire
-
Wire Gauge:
-
0.05mm~4.5mm
-
Surface:
-
bright silver
-
Packing:
-
with box or as your request
-
Varity:
-
hard wire soft wire coil wire spool wire
-
Certification:
-
AISI ASTM DIN EN JIS
-
factory experience:
-
more rhan 10 years
-
Material:
-
stainless steel 300 series
-
Product Name:
-
stainless steel wire rope
-
Product Advantage:
-
High quality Competitive price
-
Sample:
-
Free and available
| Order Source Fine Stainless Steel Wire | |
| Product name | 304 316 316L hot sale fine 25 micron stainless steel wire for mesh |
| Material | Stainless steel wire |
| Wire diamter | 0.05mm to 5.0mm |
| Length | 2m, 3m, 15m, 30m, etc. or as your require |
| Characteristics | low cost, high strength. anti- corrosion |
| Application |
Stainless steel products welding, stainless steel mesh, stainless steel products industry
|
| Package | approx 4kg/spool, 4 spools/carton, 48 cartons/pallet, approx 800kg/pallet. (coil with plastic inside woven bag outside or plastics inside hessian outside others are also available at the customers requirement.) |
| Type AISI | C Max % | Mn Max % | P Max% | S Max% | Si Max% | Cr% | Ni% | Mo% |
| 201 | 0.15 | 5.50-7.50 | 0.06 | 0.03 | 1 | 16.000-18.00 | 0.5 | - |
| 202 | 0.15 | 7.50-10.00 | 0.06 | 0.03 | 1 | 17.00-19.00 | 3.-0-5.00 | - |
| 204CU | 0.08 | 6.5-8.5 | 0.06 | 0.03 | 2 | 16.0-17.0 | 1.5-3.0 | - |
| 302 | 0.15 | 2 | 0.045 | 0.03 | 1 | 17.00-19.00 | 8.00-10.00 | - |
| 302HQ/ | 0.03 | 2 | 0.045 | 0.02 | 1 | 17.00-19.00 | 9.00-10.00 | - |
| 304CU | ||||||||
| 304HC | 0.04 | 0.80-1.70 | 0.04 | 0.015 | 0.3-0.6 | 18-19 | 8.5-9.5 | - |
| 303 | 0.07 | 2 | 0.045 | 0.25 Min | 1 | 17-19 | 8.0-10.0 | 0.6 |
| 304 | 0.08 | 2 | 0.045 | 0.03 | 1 | 18.00-20.00 | 8.0-10.50 | - |
| 304L | 0.03 | 2 | 0.045 | 0.03 | 1 | 18.00-20.00 | 8.00-12.00 | - |
| 310 S | 0.055 | 1.5 | 0.04 | 0.005 | 0.7 | 25.0-28.0 | 19-22 | - |
| 314 | 0.25 | 2 | 0.045 | 0.03 | 1.50-3.00 | 23.00-26.00 | 19.00-22.00 | - |
| 316 | 0.06 | 2 | 0.045 | 0.03 | 1 | 16.00-18.00 | 10.00-14.00 | 2.00-3.00 |
| 316L | 0.03 | 2 | 0.045 | 0.03 | 1 | 16.00-18.00 | 10.00-14.00 | 2.00-3.00 |
| 316Ti | 0.08 | 2 | 0.045 | 0.03 | 0.75 | 16.00-18.00 | 10.00-14.00 | 2.00-3.00 |
| 347 | 0.08 | 2 | 0.045 | 0.03 | 1 | 17.00-19.00 | 9.00-13.00 | - |
| 321 | 0.06 | 2 | 0.045 | 0.01 | .40-.60 | 17-19.00 | 9.4-9.6 | - |
| ER308 | 0.08 | 2 | 0.045 | 0.03 | 1 | 17-19 | 9.5-13.0 | - |
| ER308L | 0.025 | 1.50/2.00 | 0.025 | 0.02 | 0.5 | 19.0/21.0 | 9.5/11.0 | - |
| ER309 | 0.08 | 1.50/2.50 | 0.02 | 0.015 | 0.5 | 23.0/25.0 | 20.0/14.0 | - |
| ER309L | 0.025 | 1.50/2.50 | 0.02 | 0.015 | 0.5 | 23.0/25.0 | 12.0/14.0 | - |
| ER316L | 0.02 | 1.50/2.00 | 0.02 | 0.02 | 0.5 | 18.0/20.0 | 12.00-14.00 | 2.00-3.00 |
| 430L | 0.03 | 1 | 0.04 | 0.03 | 1 | 16.00-18.00 | - | |
| 434 | 0.08 | 1 | 0.04 | 0.03 | 1 | 16.00-18.00 | - | 0.90-1.40 |
production specification
|
Wire Diameter (mm) |
Allowed Difference (mm) |
Max. Diameter Difference (mm) |
|
0.020-0.049 |
+0.002
|
0.001 |
|
0.050-0.074 |
±0.002 |
0.002 |
|
0.075-0.089 |
±0.002 |
0.002 |
|
0.090-0.109 |
+0.003
|
0.002 |
|
0.110-0.169 |
±0.003 |
0.003 |
|
0.170-0.184 |
±0.004 |
0.004 |
|
0.185-0.199 |
±0.004 |
0.004 |
|
0.200-0.299 |
±0.005 |
0.005 |
|
0.300-0.310 |
±0.006 |
0.006 |
|
0.320-0.499 |
±0.006 |
0.006 |
producing
Warehouse
Quality Inspection
IF you need any help or question ,We are very welcome contact us, we will within 24 hours to reply you . as following is Contact info.:
- Free Samples .If necessary you can get free samples first to confirm our quality and then we will produce according to your requirer
- Experience :more than 10 years
- Product advantage :High quality , Competitive price
- Delivery details: Upon receipt of your purchase price (including shipping ),We will immediately produce for you . But please specify date of delivery 10- 15 days.
- Payment :T/T (30% deposit ,Balance when cargos will arrived your desination port) .
