4U 8-Socket Rack TS860M5 Inspur Server Rack Most Popular Cheap Inspur Server

Model

Description

Specifications

4U rackmount

Processor

Supports up to 8 x Intel® Xeon® series scalable processors:
Supports up to 28 cores with a frequency of 3.8 GHz
3 x UPI interconnected chains with maximum speed of 10.4 GT/s per chain, maximum power of 205W

Chipset

Intel C622/C624/C627

Memory

Supports up to 96 x DDR4 2400/2666/2933 MT/s RDIMM/LRDIMMs, can be configured to support 48 x Optane™ PMems
Each CPU supports 12 x DIMMs, 8 CPUs support 96 x DIMM/RDIMM/LRDIMMs; each DIMM supports up to 64 GB; each Optane™ PMems supports
up to 128 GB

Storage

Front: Supports up to 24 x 3.5-inch or 50 x 2.5-inch hard drives. Can be configured to support 12 x NVMe SSDs
Internal: Each compute node supports 2 x M.2 SSDs. System supports up to 4 x M.2 SSDs

Storage controller

Dedicated internal RAID card slot supports a standard RAID controller NVMe controller interface on motherboard configurable with
Intel NVMe RAID Key

Network port

The server supports 2 x OCP/PHY cards
PHY: Supports 2/4 x cards at a 1 GB/10 GB network port configuration
OCP: Supports 1/2 x cards at a 10 Gb/25 Gb network port configuration
Standard PCIe Ethernet card: Supports 1/10/25/40/100 GB

I/O expansion slot

Half-height I/O configuration: Expands up to 14 x full-length, half-height, standard PCIe slots, with 2 x internal RAID card
slots; Full-height I/O configuration: Expands up to 10 x full-length, full-height, standard PCIe slots, with 2 x internal RAID
card slots

Ports

Front: 2 x USB3.0 port, 1 x VGA port, 1 x RJ45 port
Rear: 2 x USB3.0 port, 1 x VGA port, 1 x 1 GB management port, 1 x BMC serial port
Internal: 2 x USB3.0 ports (per compute node)

Fan

16 x hot-swappable N+1 redundancy system fans

Power supply

Supports 4 x 1300W/1600W PSUs (platinum), N+N/N+M redundancy

System management

Each compute node supports 1 x BMC management module, supports IPMI, SOL, KVM Over IP, and virtual media, supports BMC mirroring
redundancy

Operating system

Supports Windows/ Red Hat/ SUSE/ Centos/ Debian/ XenServer/ Oracle Linux/ ESXi/ Ubuntu etc

Size

448mm (W) x 175.5mm (H) x 800mm (D)
17.64 inch (W) x 6.91 inch (H) x 31.50 inch (D)

Weight

Less than 110kg at full load, please refer to the technical white paper for further details

Operating temperature

0℃-40℃
32℉-104℉
Depending on configuration (please refer to the technical white paper for more details)

Performance Data

SPEC official result: Link Best application: Intel Xeon Platinum 8260 Intel Xeon Platinum 8253
