Quick Details
-
Panel Efficiency:
-
22%
-
Place of Origin::
-
Jiangsu,China
-
Type::
-
PERC, All Black, Flexible, Overlapping
-
Panel Efficiency::
-
≥23.5%
-
Warranty::
-
2YEARS
-
Current at max power (Imp)::
-
10A
-
Short circuit current(Isc):::
-
11A
-
Voltage at max power (Vmp)::
-
20V
-
Open circuit voltage(Voc)::
-
24V
Quick Details
-
Cell size:
-
158.75mmx158.75mm
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
1709*348mm
-
Panel Efficiency:
-
22%
-
Place of Origin::
-
Jiangsu,China
-
Type::
-
PERC, All Black, Flexible, Overlapping
-
Panel Efficiency::
-
≥23.5%
-
Warranty::
-
2YEARS
-
Current at max power (Imp)::
-
10A
-
Short circuit current(Isc):::
-
11A
-
Voltage at max power (Vmp)::
-
20V
-
Open circuit voltage(Voc)::
-
24V
|
Maximum Rating Power
|
W
|
100
|
120
|
180
|
200
|
250
|
260
|
|||||
|
Open Circult Voltage
|
V
|
21.58
|
24.48
|
37.30
|
40.88
|
49.35
|
49.48
|
|||||
|
Maximum Power Voltage
|
V
|
18.72
|
20.52
|
31.39
|
34.2
|
41.55
|
41.7
|
|||||
|
Short Circuit Current
|
A
|
6.85
|
6.75
|
6.81
|
6.22
|
6.39
|
6.43
|
|||||
|
Maximum Power Current
|
A
|
5.87
|
5.84
|
5.75
|
5.84
|
6.14
|
6.23
|
|||||
|
Module Efficienty
|
%
|
22
|
21.33
|
21.33
|
21.33
|
22.67
|
23.1
|
|||||
|
Power Tolerance
|
%
|
0/+3
|
0/+3
|
0/+3
|
0/+3
|
0/+3
|
0/+3
|
|||||
|
Solar Cell
|
|
32 mono 125*125mm
|
36 mono 125*125mm
|
54 mono 125*125mm
|
60mono 125*125mm
|
72 mono 125*125mm
|
|
|||||
|
Dimensions
|
|
1065*540*18mm
|
1200*540*18mm
|
1200*800*18mm
|
1320*800*18mm
|
1580*800*18mm
|
|
|||||
|
Weight
|
|
2.0kg
|
2.4kg
|
3.1kg
|
3.55kg
|
4.5kg
|
|
|||||
|
Nominal Operating Temp
|
|
45 ± 2 ℃
|
|
|
|
|
|
|||||
|
Series Fuse Rating
|
|
15A
|
|
|
|
|
|
|||||
|
Front Materials
|
|
Epoxy Fiberglass Board
|
|
|
|
|
|
|||||
