Quick Details
-
Product Model:
-
KR-S91
-
Material:
-
304 Stainless Steel+ABS+PC
-
Size:
-
91*66.2*20.3 mm
-
Tensile strength:
-
360 kg
-
Power consumption:
-
0.72W
-
Working voltage:
-
8V~24V
-
Working current:
-
60mA@12V
-
Application:
-
Logistics parcel locker, automatic vending machine, etc
-
Certification:
-
CE; FCC; RoHS
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
KERONG
-
Product Name:
-
Gym Locker Lock
-
Product Model:
-
KR-S91
-
Material:
-
304 Stainless Steel+ABS+PC
-
Size:
-
91*66.2*20.3 mm
-
Tensile strength:
-
360 kg
-
Power consumption:
-
0.72W
-
Working voltage:
-
8V~24V
-
Working current:
-
60mA@12V
-
Application:
-
Logistics parcel locker, automatic vending machine, etc
-
Certification:
-
CE; FCC; RoHS
Product Parameters
|
Brand
|
|
|
KERONG
|
|
|
||||
|
Product Model
|
|
|
KR-S91
|
|
|
||||
|
Product Name
|
|
|
Gym Locker Lock
|
|
|
||||
|
Material
|
|
|
304 Stainless Steel+ABS+PC
|
|
|
||||
|
Size
|
|
|
91*66.2*20.3 mm
|
|
|
||||
|
Weight of Lock
|
|
|
210 g
|
|
|
||||
|
Color
|
|
|
Black and Silver
|
|
|
||||
|
Surface Treatment
|
|
|
Brushed texture surface + Mold texture surface
|
|
|
||||
|
Working Voltage
|
|
|
8V~24V
|
|
|
||||
|
Working Current
|
|
|
60mA@12V
|
|
|
||||
|
Power Consumption
|
|
|
0.72W
|
|
|
||||
|
Application
|
|
|
Gym Locker, Electric Cabinet, Parcel Storage Locker, Supermarket Locker, etc
|
|
|
||||
|
Service Life
|
|
|
500,000 times
|
|
|
||||
|
Detective Switch
|
|
|
Omron
|
|
|
||||
|
Drive Mode
|
|
|
Motor
|
|
|
||||
|
Certifications
|
|
|
CE, RoHS, FCC
|
|
|
||||
Product Specification
1. Driven by motor, support 8V~24V.
2. AWG24 wire with PVC protective tube.
3. Support customizing wires and connectors.
4. Support signal unlocking, equipped with door sensor detection and push block detection.
5. Japan's Omron switch has a long service life and detects the opening and closing of the lock.
6. Different lock hooks are suitable for different locker designs and can provide customization services.
7. Equipped with an emergency unlocking lever, which can be manually unlocked in an emergency.
8. Safety: The lock shell is made of 304 stainless steel, and there will be no obvious transformation.
2. AWG24 wire with PVC protective tube.
3. Support customizing wires and connectors.
4. Support signal unlocking, equipped with door sensor detection and push block detection.
5. Japan's Omron switch has a long service life and detects the opening and closing of the lock.
6. Different lock hooks are suitable for different locker designs and can provide customization services.
7. Equipped with an emergency unlocking lever, which can be manually unlocked in an emergency.
8. Safety: The lock shell is made of 304 stainless steel, and there will be no obvious transformation.
