Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ElEMOTION
-
Dimension(L*W*H):
-
1500*1035*18500mm
-
Weight:
-
300 KG
-
Packaging speed:
-
50-60 bags/minute
-
Bag size:
-
(L)40-190mm (W)50-150mm
-
Bag making form:
-
Pillow bags, stand-up bags, hanging hole bags
-
Maximum packaging film width:
-
320mm
-
Membrane thickness:
-
0.04-0.09m
-
Air consumption:
-
0.8ps 0.25m3/min
-
Total power/voltage:
-
2KW/220V-50Hz
-
External dimension:
-
L1600*W1400H1850mm
-
Total Weight:
-
300KG
Quick Details
-
Packaging Type:
-
Stand-up Pouch, Bags, Film, Pouch
-
Packaging Material:
-
Plastic
-
Voltage:
-
220V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ElEMOTION
-
Dimension(L*W*H):
-
1500*1035*18500mm
-
Weight:
-
300 KG
-
Packaging speed:
-
50-60 bags/minute
-
Bag size:
-
(L)40-190mm (W)50-150mm
-
Bag making form:
-
Pillow bags, stand-up bags, hanging hole bags
-
Maximum packaging film width:
-
320mm
-
Membrane thickness:
-
0.04-0.09m
-
Air consumption:
-
0.8ps 0.25m3/min
-
Total power/voltage:
-
2KW/220V-50Hz
-
External dimension:
-
L1600*W1400H1850mm
-
Total Weight:
-
300KG
Full Automatic Vertical Seeds Pistachio Cashew Nuts Packaging Machine
Scope of application:
It is suitable for all kinds of leisure food ,meat products ,seafood ,fruits and vegetables, pickles, chilled meat, medical products ,hardware components, medical devices, etc.
Functional Features:
*Equipped with safety protection to meet the requirements of enterprise safety management.
*Intelligent temperature controller is adopted ,with accurate temperature control to ensure beautiful and flat sealing.
*Plc servo system ,pneumatic control system and super large display touch screen are used to form the driving control core to maximize the control accuracy ,reliability and intelligence of the while machine.
*The machine and metering configuration can automatically complete the whole packaging process of metering ,feeding ,filling and bag making , date printing ,inflation(exhaust) and finished product transportation,and automatically complete counting .
*The touch screen can store the packaging process parameters of a variety of different products ,which can be used at any time when changing products without resetting .
*It is equipped with guarantee display system ,which can help eliminate faults in time after faults occur.
*Pillow bags and perforated bags can be made according to customers needs.
*Single belt film transportation ,fast and stable ,low friction and low loss
Optional devices:
*Continuous package or multi package with short package cut-off function.
*Hook hole drilling function (round holes and various irregular holes can be drilled)
*Supporting discharge conveyor.
*Various automatic or semi-automatic metering and conveying mechanisms,
*Inflation and exhaust function.
*Compressed air system and nitrogen generator.
Products Description
|
Model number
|
YD-320
|
YD-420
|
YD-520
(PE/composite film)
|
YD-720
(PE/composite film)
|
|||
|
Packing bag material
|
Pillow bags, stand-up bags, hanging hole bags
|
|
|
|
|||
|
Packing bag specification
|
W:50*150mm
L：40*190mm |
W:80*200mm
L：80*300mm |
W：140-250mm
L：100-420mm |
W：150*350mm
L：150*450mm |
|||
|
Packing speed
|
≤90 packet/min
|
≤90 packet/min
|
≤50 packet/min
|
≤40 packet/min
|
|||
|
Air consumption
|
6-8kgf/㎡,0.15m³/min
|
6-8kgf/㎡ 0.15m³/min
|
6-8kgf/㎡，0.6m³/min
|
6-8kgf/㎡，0.6m³/min
|
|||
|
Power
|
AC220V,50-60HZ,2.3KW
|
AC220V,50-60HZ,3KW
|
AC220V,50-60HZ,3.5KW
|
AC220V,50-60HZ,4KW
|
|||
|
Overall dimension
|
950*650*1750mm
|
500*1035*1850mm
|
1600*1400*900mm
|
1600*1400*2000mm
|
|||
