Quick Details
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
jingong
-
Model Number:
-
hand winch
-
material:
-
steel and iron
-
finish:
-
Color painted
-
product name:
-
wheel pulley
-
OEM:
-
Available
-
Type:
-
Permanent
-
Warranty:
-
one year
-
Package:
-
standard export carton
-
Efficiency:
-
high
Quick Details
-
Power Source:
-
Hand
-
Application:
-
BOAT
-
Capacity:
-
2600
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
jingong
-
Model Number:
-
hand winch
-
material:
-
steel and iron
-
finish:
-
Color painted
-
product name:
-
wheel pulley
-
OEM:
-
Available
-
Type:
-
Permanent
-
Warranty:
-
one year
-
Package:
-
standard export carton
-
Efficiency:
-
high
- Positive Weston-style brake will hold the load in any position.
- Compact, lightweight and rugged construction.
- Mechanical components enclosed for protection and safety.
- Available with a powder-coated or a marine-coated corrosion resistant finish.
- Rope to drum fixing clamp provided.
- Heat-treated gears.
- Strong removable handles.
- High precision construction minimises gear noise.
- AS1418.2 Compliance applies when correctly fitted with approved wire rope and fittings.
- BHW models available with marine-coated Kylan finish.
- BHW1200 / BHW1800 / BHW2600 also available in stainless steel
| AS 1418.2 Compliance applies when fitted with approved wire ropes and fittings. | ||||
| Model: | BHW-800 | BHW-1200 | BHW-1800 | BHW-2600 |
| Capacity (kg) pull-lift | 370-180 | 545-270 | 820-410 | 1200-600 |
| Hand force required (kg) | 14.5 | 15 | 22 | 19 |
| Gear ratio | 4.1:1 | 4.1:1 | 5.0:1 | 10.0:1 |
| Hub diameter (mm) | Φ40 | Φ50 | Φ70 | Φ80 |
| Handle length (mm) | 160 | 210 | 320 | 320 |
| Unit weight (kg) | 3 | 3.3 | 8 | 10.3 |
| Rope diameter (mm) | Φ4 | Φ5 | Φ7 | Φ8 |
| Ropes storage capacity (m) | 36 | 23 | 24 | 18 |
