Quick Details
-
Brand Name:
-
JXPC or OEM
-
Products Name:
-
2W160-15 Series 2 way Direct Acting Solenoid Valve
-
Operation:
-
Direct Acting
-
Orifice Size(mm):
-
4, 2.5, 2 , 1.2
-
CV Value:
-
0.6, 0.23, 0.15, 0.05,
-
Operation Fluid Viscosity:
-
Below 23 CST
-
Operating Pressure:
-
0~0.7Mpa / 0~0.2Mpa
-
Operating Temperature:
-
NBR for -5~80°C and KFM for -5~80°C
-
Voltage Range:
-
±10%
-
Material of Oil Seal:
-
NBR,EPDM or KFM
Quick Details
-
Port Size:
-
G1/8",G1/4 ", G3/8"
-
Place of Origin:
-
Zhejiang, China
-
Model Number:
-
2W160-15
-
Brand Name:
-
JXPC or OEM
-
Products Name:
-
2W160-15 Series 2 way Direct Acting Solenoid Valve
-
Operation:
-
Direct Acting
-
Orifice Size(mm):
-
4, 2.5, 2 , 1.2
-
CV Value:
-
0.6, 0.23, 0.15, 0.05,
-
Operation Fluid Viscosity:
-
Below 23 CST
-
Operating Pressure:
-
0~0.7Mpa / 0~0.2Mpa
-
Operating Temperature:
-
NBR for -5~80°C and KFM for -5~80°C
-
Voltage Range:
-
±10%
-
Material of Oil Seal:
-
NBR,EPDM or KFM
Product Description
- 2 Way Solenoid Valve, G1/8",G1/4 ", G3/8" Port Size , Stainless Steel or Brass
- High Quality Normally Closed electric solenoid valve, for Air,Water,Oil,Gas
- Working temperature range: -5~80°C
- It's applicable in many fields: Irrigation controls (garden, farm,etc.), liquid controls ( pipeline, artificial river etc. and air controls ( lab, factory, etc.)
- We have solenoids available in AC/DC and various size NPT threads as welll
| 2W Series 2/2 way Direct Acting Solenoid Valve | ||||||
| Model | 2W025-06 | 2W025-08 | 2W040-10 | 2WH012-06 | 2WH012-08 | 2WH020-10 |
| Medium | Air,Water,Oil,Gas | |||||
| Operation | Direct Acting | |||||
| Type | Normal Close | |||||
| Orifice Size(mm) | 2.5 | 4 | 1.2 | 2 | ||
| CV Value | 0.23 | 0.6 | 0.05 | 0.15 | ||
| Port Size | G1/8" | G1/4" | G3/8" | G1/8" | G1/4" | G3/8" |
| Operation Fluid Viscosity | Below 23 CST | |||||
| Operating Pressure | Air,Water,Oil,Gas:0~0.7Mpa | Air,Water,Oil,Gas:0~0.2Mpa | ||||
| Max Pressure Resistance | 1.0MPa | 3.5MPa | ||||
| Operating Temperature | NBR for -5~80°C and VITON for -5~80°C | |||||
| Voltage Range | ±10% | |||||
| Material of Body | Stainless Steel or Brass | |||||
| Material of Oil Seal | NBR,EPDM or VITON | |||||
