This machine is suitable for food and beverage production water, beer and injection water for pharmaceutical industry and seawater desalination system, etc.
- Product Details
- {{item.text}}
Quick Details
-
Application:
-
Beverage/Pure Water/Juice/Soft Drinks
-
Suitable For:
-
Well Water/Underground Water
-
After-sales Service Provided:
-
Free spare parts, Field installation, commission and training
-
Function:
-
make water pure clean
-
Kind of Business:
-
Factory Manufacturer
-
Usage:
-
Pure Water Process
-
Type:
-
water treatment equipment
-
Keywords:
-
RO Water Filtration
Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
HZM
-
Weight (KG):
-
3000 kg
-
Application:
-
Beverage/Pure Water/Juice/Soft Drinks
-
Suitable For:
-
Well Water/Underground Water
-
After-sales Service Provided:
-
Free spare parts, Field installation, commission and training
-
Function:
-
make water pure clean
-
Kind of Business:
-
Factory Manufacturer
-
Usage:
-
Pure Water Process
-
Type:
-
water treatment equipment
-
Keywords:
-
RO Water Filtration
PRODUCT OVERVIEW
Beverage industry drinking pure distill mineral water treatment machinery ro plant lake river well water purification system
The water treatment process is basically divided into three parts: pretreatment system, deep treatment system and terminal treatment system. Generally, pretreatment includes multi-media filters, activated carbon filter, softener, iron and manganese removal filter, ultra-filtration, micro-filtration.,etc. Deep treatment includes membrane treatment and ion exchange.
Terminal treatment covers ozone, UV, etc.
PRODUCT DESCRIPTION
Pretreatment system
Sand filter
Also known as "mechanical filter" or "Multi media filter" Composition: mainly composed of pressure vessel and Filter material composition. Particle size difference is laid in layers under pressure a filter bed is formed in the pressure vessel.
Function
Activated carbon filter
is composed the activated carbon filter is composed of pressure vessel and activated carbon filter material.
Function
Softening device
is composed of ion exchange resin (multi sodium type), pressure vessel, salt tank and regeneration cleaning control mechanism.
Function
2RNa+Ca2+=R2 Ca+2Na+
2RNa+Mg2+=R2Mg+2Na+
2RNa+Mg2+=R2Mg+2Na+
Precision filter (or security filter)
it is composed of filter element (filter element with pore diameter ≤ 5 microns is recommended) and stainless steel pressure vessel.
Function
Flocculant:
when the suspended solids content in the water source is high, adding a certain concentration of flocculant can further reduce the pollution index SDI. The mechanism is to destroy the electrical neutrality of colloid and make it flocculate and precipitate.
Scale inhibitor:
adding an appropriate amount of scale inhibitor into the RO inlet water can inhibit the scaling of minerals on the surface of reverse osmosis membrane (concentrated water side).
Deep treatment
Reverse osmosis is a membrane separation technology, which is a process of separating solvent and solute under pressure.
Termital treatment
Ultraviolet disinfection
nucleoproteins in microorganisms are denatured due to the absorption of broad-spectrum ultraviolet energy, causing metabolic
disorders and loss of reproductive ability. When the irradiation dose increases to a certain amount, the microbial cells are
destroyed and killed.
disorders and loss of reproductive ability. When the irradiation dose increases to a certain amount, the microbial cells are
destroyed and killed.
Ozone disinfection
Ozone is a strong oxidant, and the sterilization process is a biochemical oxidation reaction.
