Quick Details
-
Size:
-
14000*3000*4000mm or Customized
-
Place of Origin:
-
Shandong, China
-
Main Beam Spec.:
-
T700/Q345 Steel, Height:500mm, Plate Thickness:8-16mm
-
Side Frame:
-
Channel Steel
-
Cross Brace:
-
Channel Steel/Bending Steel
-
King Pin:
-
2"(50mm)or3.5"(90mm) JOST Brand
-
Leaf Spring:
-
10-layers leaf
-
Tire:
-
12R22.5, 11.00R20, 12.00R20, 315/80R22.5
-
Brake Chamber:
-
2sets
-
Electric System:
-
24V, One Set 6-core Standard Cable
-
Light:
-
Tail lamp with turn signal,brake light & reflector,side lamp etc
-
Packing:
-
Ro-ro Shipment, Frame Work or Optional
Quick Details
-
Type:
-
Semi-Trailer
-
Max Payload:
-
80T
-
Brand Name:
-
EAST
-
Size:
-
14000*3000*4000mm or Customized
-
Place of Origin:
-
Shandong, China
-
Main Beam Spec.:
-
T700/Q345 Steel, Height:500mm, Plate Thickness:8-16mm
-
Side Frame:
-
Channel Steel
-
Cross Brace:
-
Channel Steel/Bending Steel
-
King Pin:
-
2"(50mm)or3.5"(90mm) JOST Brand
-
Leaf Spring:
-
10-layers leaf
-
Tire:
-
12R22.5, 11.00R20, 12.00R20, 315/80R22.5
-
Brake Chamber:
-
2sets
-
Electric System:
-
24V, One Set 6-core Standard Cable
-
Light:
-
Tail lamp with turn signal,brake light & reflector,side lamp etc
-
Packing:
-
Ro-ro Shipment, Frame Work or Optional
Products Description
|
Overall Dimension
|
14000*3000*4000mm or Customized
|
|
Curb Weight
|
12T
|
|
Loading Capacity
|
80T
|
|
Main Beam Spec.
|
T700/Q345 Steel, Height:500mm, Plate Thickness:8-16mm
|
|
Side Frame
|
Channel Steel
|
|
Cross Brace
|
Channel Steel/Bending Steel
|
|
Suspension
|
Mechanical Spring or Air Suspension System
|
|
|
Tandem or Single Suspension
|
|
Leaf Spring
|
10-layers leaf spring(90mm*13mm*10pcs)
|
|
Axle Spec.
|
13T/16T/20T BPW or FUWA or EAST
|
|
Landing Gear
|
heavy duty 28ton landing leg
|
|
King Pin
|
2"(50mm)or3.5"(90mm) JOST Brand
|
|
Tire
|
12R22.5, 11.00R20, 12.00R20, 315/80R22.5
|
|
Brake Chamber
|
2sets
|
|
Electric System
|
24V, One Set 6-core Standard Cable
|
|
Light
|
Tail lamp with turn signal,brake light & reflector,side lamp etc
|
|
Painting
|
Sand blasting, prime coating, surface painting,color optional, wax polishing
|
|
Packing
|
Ro-ro Shipment, Frame Work or Optional
|
