Quick Details
-
Warranty:
-
25 years for power output
-
Brand Name:
-
Sunry
-
Model Number:
-
SR395-415-108M8-H
-
Place of Origin:
-
Henan, China
-
Panel Dimensions:
-
1722x1134x30mm
-
Frame:
-
Anodized aluminium alloy
-
Front cover:
-
3.2mm High Transmissivity, Low Iron tempered glass
-
Frame Color:
-
Silver, Black, Full black
-
Keyword:
-
home solar panel 410w
-
Packing:
-
36pcs/pallet, 962pcs/40HQ
-
Panel weight:
-
19kg
-
OEM:
-
Acceptable
-
Certificate:
-
CE, TUV, ISO, CQC, IEC
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell, All Black
-
Panel Efficiency:
-
21.3%
-
Warranty:
-
25 years for power output
-
Brand Name:
-
Sunry
-
Model Number:
-
SR395-415-108M8-H
-
Place of Origin:
-
Henan, China
-
Panel Dimensions:
-
1722x1134x30mm
-
Frame:
-
Anodized aluminium alloy
-
Front cover:
-
3.2mm High Transmissivity, Low Iron tempered glass
-
Frame Color:
-
Silver, Black, Full black
-
Keyword:
-
home solar panel 410w
-
Packing:
-
36pcs/pallet, 962pcs/40HQ
-
Panel weight:
-
19kg
-
OEM:
-
Acceptable
-
Certificate:
-
CE, TUV, ISO, CQC, IEC
Products Description
Product Paramenters
|
Module Type
|
SR(395-415)-108M8-H
|
SRxxx-108M8-H
|
SR405-108M8-H
|
SR410-108M8-H
|
SR415-108M8-H
|
||||
|
Maximum Power at STC-Pmp (W)
|
395
|
400
|
405
|
410
|
415
|
||||
|
Open Circuit Voltage-Voc (V)
|
36.92
|
37.12
|
37.22
|
37.32
|
37.42
|
||||
|
Short Circuit Current-Isc (A)
|
13.52
|
13.60
|
13.70
|
13.80
|
13.90
|
||||
|
Maximum Power Voltage-Vmp (V)
|
30.76
|
30.81
|
30.93
|
31.05
|
31.16
|
||||
|
Maximum Power Current-Imp (A)
|
12.84
|
12.99
|
13.10
|
13.21
|
13.32
|
||||
|
Module Efficiency at STC -(%)
|
20.3
|
20.5
|
20.8
|
21.00
|
21.3
|
||||
Note:
1.Standard Test Conditons[STC]: irradiance 1000W/M2 ; >AM1.5; ambient temperature 25°C according to EN 60904-3;
2.Normal Operating Cell Temperature[NOCT]: irradiance 800W/m2; wind speed 1m/s, cell temperature 45 °C; ambient temperature 20°C.
3.Tolemrance Of Pm:0~ + 5%, measuring uncertainty of power:±3%. Performance deviation of Voc[V],lsc[A],Vm[V] and lm[A]:±5%.
2.Normal Operating Cell Temperature[NOCT]: irradiance 800W/m2; wind speed 1m/s, cell temperature 45 °C; ambient temperature 20°C.
3.Tolemrance Of Pm:0~ + 5%, measuring uncertainty of power:±3%. Performance deviation of Voc[V],lsc[A],Vm[V] and lm[A]:±5%.
