Quick Details
-
Place of Origin:
-
Fujian, China
-
Curb Weight:
-
19350 Kgs
-
Shape:
-
OVAL
-
Medium:
-
Petrochemical liquid
-
Body Steel Material:
-
Q345B / 5mm
-
End Plates:
-
Q345B / 6mm, by punching
-
Resistant Wave Plates:
-
Q345B / 3mm
-
Partition Chamber Plates:
-
Q345B / 5mm
-
Overall LxWxH:
-
13000x2500x3995mm
-
Wheelbase:
-
7180+1310+1310mm
Quick Details
-
Type:
-
Semi-Trailer
-
Max Payload:
-
47500L
-
Brand Name:
-
WONDEE
-
Place of Origin:
-
Fujian, China
-
Curb Weight:
-
19350 Kgs
-
Shape:
-
OVAL
-
Medium:
-
Petrochemical liquid
-
Body Steel Material:
-
Q345B / 5mm
-
End Plates:
-
Q345B / 6mm, by punching
-
Resistant Wave Plates:
-
Q345B / 3mm
-
Partition Chamber Plates:
-
Q345B / 5mm
-
Overall LxWxH:
-
13000x2500x3995mm
-
Wheelbase:
-
7180+1310+1310mm
|
Specification |
||
|
Type |
LNG Transport Truck Tank semi trailer Liquid Nitrogen Trailer for Sale |
|
|
Tank Capacity (M 3 ) |
45.70 |
|
|
Overall Dimension (mm) |
13000x2500x3995 |
|
|
Tank Dimension (mm) |
12850x2498 |
|
|
Payload (mm) |
20650 |
|
|
Wheel Base |
7180+1310+1310 |
|
|
Rear Tread (mm) |
1830/1830/1830 |
|
|
Gross Weight (kg) |
4000 |
|
|
Curb Weight (kg) |
19350 |
|
|
Front / Rear Overhang (mm) |
1550 |
|
|
Main configuration |
||
|
Shell Of Tanker |
Products |
LPG, Butane , Propane |
|
Fluidproperty |
Flammable |
|
|
Design Temperature |
50°C |
|
|
Design Pressure |
1.61MPa |
|
|
Corrosion Allowance |
1.0mm |
|
|
Major Materials of Bearing Pressure |
Tanker body: Q370R |
|
|
End plate: Q370R |
||
|
Main Beam: Q345B |
||
|
Compartments |
One |
|
|
Baffle Inside The Tank |
14-off Aluminium bolted plate , |
|
|
Thickness is 5mm |
||
|
Shape |
Cylindrical ; Ellipse head |
|
|
Safety Valve |
Quantity |
Two |
|
Location |
On the top of tanker ; |
|
|
Type |
Only weld suitable flange |
|
|
Size |
As customer's requirement |
|
|
Running System |
Axles |
3 Units 13 TON WONDEE Brand Axles |
|
Suspension System |
3 Alxes American Type Mechanical Suspension |
|
|
Wheel Rim |
12 units 9.00-22.5 rims |
|
|
Tyre |
12 units 12R22.5 tires |
|
|
Kingpin |
One unit 3.5” bolt-in kingpin |
|
|
Landing Gear |
Two speed manual operation 19” linked landing gear |
|
|
Pneumatic Braking System |
WABCO RE 6 relay valve; Spring brake chamber; 2 pieces of 45L air tanks |
|
|
Electronical System |
7-Pin Socket |
24V 7-pin socket |
|
LED Lamp |
All kinds of lamp |
|
|
Cable |
Stander cable |
|
|
LNG Trailer Payment & Terms |
||
|
* MOQ: |
1 Unit |
|
|
* Payment Terms: |
L/C, T/T, Western Union |
|
|
* Supply Capacity: |
100 Units per Month |
|
|
* Delivery Time: |
About 25 Working Days |
|
|
* Delivery Port: |
China Port |
|
|
* Package: |
2 Units LNG Trailer in 2x40'HQ and 1*20'GP |
|
The Drawing about LNG Trailer:
LNG Transport Truck Tank semi trailer Liquid Nitrogen Trailer for Sale Packing Photos:
