- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
R
-
Certification:
-
ce
-
Output Voltage:
-
12V/24/48V
-
rotor diameter:
-
0.9~1.8M
-
Max Power:
-
100~1000W
-
Application:
-
Wind Power System
-
Color:
-
Customers' Requirement
-
Rated Voltage:
-
12v/24v/48v
-
Survival wind speed:
-
45.0m/s
-
Start wind speed:
-
2m/s
-
Controller:
-
Wind Controller
-
WEIGHT:
-
11~28kg
-
Working system:
-
Wind Solar Hybrid
-
Material:
-
Nylon fibre
Quick Details
-
Rated Power:
-
100~10000W
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
HUYI
-
Model Number:
-
R
-
Certification:
-
ce
-
Output Voltage:
-
12V/24/48V
-
rotor diameter:
-
0.9~1.8M
-
Max Power:
-
100~1000W
-
Application:
-
Wind Power System
-
Color:
-
Customers' Requirement
-
Rated Voltage:
-
12v/24v/48v
-
Survival wind speed:
-
45.0m/s
-
Start wind speed:
-
2m/s
-
Controller:
-
Wind Controller
-
WEIGHT:
-
11~28kg
-
Working system:
-
Wind Solar Hybrid
-
Material:
-
Nylon fibre
Products Description
|
product name
|
Wind power generation system
|
|
warranty period
|
1 year
|
|
working time
|
24 hours
|
|
output voltage
|
12V/24V/48V
|
|
Paed power
|
100W~10000W
|
|
Max power
|
150W~12000W
|
|
Start-up wind speed
|
2m/s
|
|
Model
|
R1-100W
|
R1-200W
|
R1-300W
|
R1-500W
|
R1-1000W
|
||||
|
Rated power
|
100W
|
200W
|
300W
|
500W
|
1000W
|
||||
|
Maximum power
|
150W
|
250W
|
350W
|
550W
|
1100W
|
||||
|
Rated voltage
|
12V/24V
|
12V/24V
|
12V/24V
|
12V/24V
|
12V/24V/48V
|
||||
|
Start-up wind speed
|
2m/s
|
2m/s
|
2m/s
|
2m/s
|
2m/s
|
||||
|
Rated wind speed
|
11m/s
|
11.5m/s
|
12m/s
|
12m/s
|
11m/s
|
||||
|
Survival wind speed
|
45m/s
|
45m/s
|
45m/s
|
45m/s
|
45m/s
|
||||
|
Top net weight
|
11kg
|
11.5kg
|
12kg
|
15kg
|
28kg
|
||||
|
Wheel diameter
|
0.9m
|
0.9m
|
0.9m
|
0.9m
|
1.8m
|
||||
|
Blade height
|
0.6m
|
0.6m
|
0.6m
|
0.6m
|
0.9m
|
||||
|
Number of blades
|
5 pcs
|
|
|
|
|
||||
|
Blades material
|
Nylon fibre
|
|
|
|
|
||||
|
Body material
|
Nylon fibre
|
|
|
|
|
||||
|
Control system
|
Electromagnetic brake
|
|
|
|
|
||||
|
Yaw mode
|
Automatic windward angle
|
|
|
|
|
||||
|
Lubrication method
|
Self lubrication
|
|
|
|
|
||||
|
Tower form
|
inhaul cable /Independent tower
|
|
|
|
|
||||
|
Working temperature
|
-40℃～80℃
|
|
|
|
|
||||
The diameter of the wind wheel is 0.9~1.8m,
including: generator, blade, tail rudder, hood hub
Battery
> Agm Battery
> Gel Battery
> 2V,12V
Without a battery bank (or a generator) it'll be lights out by sunset. A battery bank is essentially a group of batteries wired
together
> Gel Battery
> 2V,12V
Without a battery bank (or a generator) it'll be lights out by sunset. A battery bank is essentially a group of batteries wired
together
Off Grid Inverter
> Input Voltage from 12V to 1000V
> Input Ampere 5A to 200AH
> Output voltage 110/220V/380v/400V
> Single phase and Three phase
