Quick Details
-
Warranty:
-
1 year
-
Brand Name:
-
SEAFLO
-
Model Number:
-
SFDPA1-050-055-42W
-
Place of Origin:
-
Fujian, China
-
Outlet Size:
-
1/2"-14 MNPT
-
Max Flow Rate:
-
5.0 GPM [18.9 LPM]
-
Max Pressure:
-
55 PSI [3.8 Bar]
-
Switch Type:
-
On Demand & By Pass
-
Diaphragm Material:
-
Santoprene
-
Valve Material:
-
Fluororubber or EPDM
-
Self Priming:
-
6' [1.8 m] Suction
-
Max Fluid Temp.:
-
140 °F [60 °C]
-
Duty Cycle:
-
Intermittent
-
Fuel:
-
Battery, Solar Power or Transformer
Quick Details
-
Application:
-
Drinking water treatment, Family Homes, Food and Beverage Industry, Irrigation and Agriculture, Marine, Washing and Cleaning
-
Pressure:
-
Low Pressure
-
Voltage:
-
115 / 230V AC
-
Warranty:
-
1 year
-
Brand Name:
-
SEAFLO
-
Model Number:
-
SFDPA1-050-055-42W
-
Place of Origin:
-
Fujian, China
-
Outlet Size:
-
1/2"-14 MNPT
-
Max Flow Rate:
-
5.0 GPM [18.9 LPM]
-
Max Pressure:
-
55 PSI [3.8 Bar]
-
Switch Type:
-
On Demand & By Pass
-
Diaphragm Material:
-
Santoprene
-
Valve Material:
-
Fluororubber or EPDM
-
Self Priming:
-
6' [1.8 m] Suction
-
Max Fluid Temp.:
-
140 °F [60 °C]
-
Duty Cycle:
-
Intermittent
-
Fuel:
-
Battery, Solar Power or Transformer
Products Description
Product Paramenters
|
Model
|
Voltage
|
Voltage range
|
Open Flow
（GPM/LPM）
|
Max
Draw
|
Shut-off Pressure
（PSI/BAR)
|
|
SFDP1-030-055-42W
|
12V
|
8.4V~15.6V
|
3.0 / 11.3
|
8.0
|
55 / 3.8
|
|
SFDP2-030-055-42W
|
24V
|
16.8V~31.2V
|
3.0 / 11.3
|
5.0
|
55 / 3.8
|
|
SFDPA1-030-055-42W
|
115V
|
90V~140V（AC）
|
3.0 / 11.3
|
2.0
|
55 / 3.8
|
|
SFDPA2-030-055-42W
|
230V
|
180V~250V（AC）
|
3.0 / 11.3
|
1.0
|
55 / 3.8
|
|
SFDP1-040-055-42W
|
12V
|
8.4V~15.6V
|
4.0 / 15.1
|
10.0
|
55 / 3.8
|
|
SFDP2-040-055-42W
|
24V
|
16.8V~31.2V
|
4.0 / 15.1
|
8.0
|
55 / 3.8
|
|
SFDPA1-040-055-42W
|
115V
|
90V~140V（AC）
|
4.0 / 15.1
|
3.0
|
55 / 3.8
|
|
SFDPA2-040-055-42W
|
230V
|
180V~250V（AC）
|
4.0 / 15.1
|
1.4
|
55 / 3.8
|
|
SFDP1-050-055-42W
|
12V
|
8.4V~15.6V
|
5.0 / 18.9
|
10.0
|
55 / 3.8
|
|
SFDP2-050-055-42W
|
24V
|
16.8V~31.2V
|
5.0 / 18.9
|
8.0
|
55 / 3.8
|
|
SFDPA1-050-055-42W
|
115V
|
90V~140V（AC）
|
5.0 / 18.9
|
3.0
|
55 / 3.8
|
|
SFDPA2-050-055-42W
|
230V
|
180V~250V（AC）
|
5.0 / 18.9
|
1.5
|
55 / 3.8
|
