Quick Details
-
Jacket:
-
PVC
-
Place of Origin:
-
Henan, China
-
Product name:
-
Armoured Cable
-
Color:
-
Black
-
Core:
-
1core or Multicore
-
Certificate:
-
CE, ISO9001,CCC
-
Armour:
-
Steel Tape /steel wire Armor
-
Rated voltage:
-
600/1000V
-
Sample:
-
Free available
-
Oem:
-
provided
Quick Details
-
Insulation Material:
-
Xlpe
-
Application:
-
Industrial
-
Conductor Material:
-
Copper
-
Jacket:
-
PVC
-
Place of Origin:
-
Henan, China
-
Product name:
-
Armoured Cable
-
Color:
-
Black
-
Core:
-
1core or Multicore
-
Certificate:
-
CE, ISO9001,CCC
-
Armour:
-
Steel Tape /steel wire Armor
-
Rated voltage:
-
600/1000V
-
Sample:
-
Free available
-
Oem:
-
provided
Application:
1. Operating Features:
The maximum conductor operating temperature: 90°C
During short circuit (lasting less than 5 seconds) the maximum temperature of the cable conductor shall not be above 250°C
Environment temperature should be no lower than 0°C for laying the cable.
2. Bending Radius of the Cable:
Single Core Cable: Non Armored Cable 20D, Armored Cable 15D.
Cores Cable: Non Armored Cable 15D, Armored Cable 12D.
Usage:
The product is suitable for use in power distribution lines or fixed installations with rated power- frequency voltage up to and including 1Kv, AC 50Hz.
