Quick Details
-
Voltage:
-
100V/110/220V/230V
-
Dimension(L*W*H):
-
L56xW40(48)xH41CM
-
Weight:
-
36 KG
-
Power:
-
865KW
-
Working Temperature Range:
-
-5℃~RT
-
Compressor:
-
"Mitsubishi" / "Copeland"
-
Application:
-
New energy
-
Product name:
-
Water Cooled Chiller
-
Refrigerant:
-
R22/R407C/R134a/R404A
-
Cooling type:
-
Air cooling
-
Cooling method:
-
Single-stage refrigeration / multi-machine parallel
-
Cooling capacity:
-
2.5kw/3.5kw/5.2kw/7.5kw
-
Marketing Type:
-
New Product 2024
-
Name:
-
Water Chiller Water Cooler Machine
Quick Details
-
Condition:
-
New
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
T&HLS
-
Voltage:
-
100V/110/220V/230V
-
Dimension(L*W*H):
-
L56xW40(48)xH41CM
-
Weight:
-
36 KG
-
Power:
-
865KW
-
Working Temperature Range:
-
-5℃~RT
-
Compressor:
-
"Mitsubishi" / "Copeland"
-
Application:
-
New energy
-
Product name:
-
Water Cooled Chiller
-
Refrigerant:
-
R22/R407C/R134a/R404A
-
Cooling type:
-
Air cooling
-
Cooling method:
-
Single-stage refrigeration / multi-machine parallel
-
Cooling capacity:
-
2.5kw/3.5kw/5.2kw/7.5kw
-
Marketing Type:
-
New Product 2024
-
Name:
-
Water Chiller Water Cooler Machine
Product Description
Main Features of lab circulating chiller
1) Controllable temperature and flow, to provide a thermostatic environment
2) Equipped with a inside cooling bath for direct cooling materials inside
3) Digital display of temperature makes the temperature setting simple and flexibly Efficient and secure temperature conversion
4) Safe in operation, easy to move around with casters with lock
5) A variety of fault alarm (over temperature alarm, sensor alarm, high pressure alarm, compressor overheat alarm, liquid level alarm)
6) Closed cycle pipeline design to prevent circulating water from pollution and extend the lifetime of circulation liquid.
7) Circulating system adopts SUS304 stainless steel material and macromole anti-corrosion material, which can prevent rust,corrosion and low temperature liquid pollution
2) Equipped with a inside cooling bath for direct cooling materials inside
3) Digital display of temperature makes the temperature setting simple and flexibly Efficient and secure temperature conversion
4) Safe in operation, easy to move around with casters with lock
5) A variety of fault alarm (over temperature alarm, sensor alarm, high pressure alarm, compressor overheat alarm, liquid level alarm)
6) Closed cycle pipeline design to prevent circulating water from pollution and extend the lifetime of circulation liquid.
7) Circulating system adopts SUS304 stainless steel material and macromole anti-corrosion material, which can prevent rust,corrosion and low temperature liquid pollution
Specification
|
Cooled Water Circulation System
|
|
|
|
|
||||
|
Model
|
TLW-01A
|
TLW-01hA
|
TLW-02A
|
TLW-03A
|
||||
|
Control Temperature
|
Default5℃～RT(Room Temperature);the lowest temperature can be -5℃ for factory setting
|
|
|
|
||||
|
Refrigerature Method
|
Electronic expansion valve
|
|
|
|
||||
|
Temperature Control Accuracy
|
<1
.5°C(High accuracy customization is supported)
|
|
|
|
||||
|
Refrigerants
|
Default R22;optional R407C、R134a、R404A
|
|
|
|
||||
|
Cooling Capacity KW
|
2.5KW
|
3.5 KW
|
5.2 KW
|
7.5 KW
|
||||
|
Flow max L/min
|
25L/min
|
50L/min
|
50L/min
|
70L/min
|
||||
|
Lift M
|
18
|
10
|
|
|
||||
|
Interface Specifications
|
G1/2
|
G3/4
|
G3/4
|
G3/4
|
||||
|
Weight kg
|
36kg
|
45kg
|
53kg
|
68kg
|
||||
|
Power supply
|
AC380V/50HZ
|
|
|
|
||||
|
Outer Size(cm)
|
L56xW40(48)xH41
|
L56xW40(48)xH43
|
L62xW51xH47
|
L62xW53xH65
|
||||
|
Remarks
|
Be based on the temperature of 25°C
|
|
|
|
||||
|
|
Power supply is optional,100V 50HZ single Phase、110V 60HZ single phase、230V 60HZ single phase、220V 60HZ three phase.
|
|
|
|
||||
Detail advantage
All improtant components are imported from Europe ,the United States,and Japan ............
Product Type
Type 1
Type 2
Type 3
Packing & Delivery
Packaging: polywood case for temperature humidity incubator
