Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Sanhok
-
Dimension(L*W*H):
-
60*8000m /Non-standard customization
-
Product name:
-
conveyor
-
Application:
-
Factory production line, express logistics, warehousing and handling
-
Usage:
-
Transport products in assembly line
-
Weight:
-
1000KG
-
Motor Brand:
-
Taibang ,Sew
-
Type:
-
sus201 / sus 304
-
Main classification:
-
Powered/ Unpowered /Heavy Duty /Light/ Sprocket Roller Conveyor
Quick Details
-
Power:
-
2.2 KW, 1.5 KW, 0.75 KW
-
Warranty:
-
1 Year
-
Width or Diameter:
-
20mm
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Sanhok
-
Dimension(L*W*H):
-
60*8000m /Non-standard customization
-
Product name:
-
conveyor
-
Application:
-
Factory production line, express logistics, warehousing and handling
-
Usage:
-
Transport products in assembly line
-
Weight:
-
1000KG
-
Motor Brand:
-
Taibang ,Sew
-
Type:
-
sus201 / sus 304
-
Main classification:
-
Powered/ Unpowered /Heavy Duty /Light/ Sprocket Roller Conveyor
Product Description
Conveyor Belt Manufacturer
Low Cost Technology Roller Gravity Conveyor For Pharmaceutical Industry
Cost-effective gravity rollers can be used for many purposes including:
1
.As transfer sections between belt conveyors or live roller conveyors
2
.For storing empty or filled containers
3.
For transferring empty containers to workstations or full containers to shipping
The non-powered straight roller conveyor transports materials either manually or via gravity down a slope and is used as an assembly and picking line.
The non-powered roller conveyor curve changes the transport direction of materials. Material is manually pushed around the curve. The alignment of the material is maintained within the side frames by tapered rollers.
Specification
Due to different product specifications, sizes, and need to be customized, the price on the page is for reference only. Please contact us at any time to tell us your needs, we will give you a satisfactory price
Unpowered Roller Conveyor
Size Chart
|
Supporting frame
|
40*40*T2.0mm Aluminum
|
|
|
Guide rail
|
40*80*2.0mm Aluminum
|
|
|
Transfer parts
|
￠60 gravity rollers,200mm pitch
|
|
|
Lighting
|
40W double fluorescent lamps with cover
|
|
|
Air pipe
|
3/4”galvanized air pipe with air cock
|
|
|
40*80 galvanized wire slot
|
made by T1.0 galvanized sheet，sockets with 2 seats and 3 holes.
|
|
|
Feet
|
M12*80mm galvanized leveling feet，±30mm adjustability；
|
|
|
Tooling box hanger
|
W50*T5mm Aluminum。
|
|
|
Instruction board
|
H model aluminum，one A4 sheet file pack per meter；
|
|
Details Images
The roller conveyor is mainly composed of rollers, racks, brackets, driving parts, etc.
Roller conveyor parts size display
Bracket:
made of 40 * 80 * 1.5 aluminum profiles;
Guide rail
: adopt 40 * 120 roller line special rail profile;
Drum:
made of single row chain wheel with 4 points and 11 teeth welded by No 60 galvanized pipe
Foot cup:
M16 * 80 galvanized pin cup with hole is adopted;
Motor
: 750W conjoined motor (Chuanming) with Yineng inverter is adopted.
The installation spacing is 100 mm;
Classification
Rollers & roller conveyors rely on the friction between the rotating rollers and the items to move the items forward. According to the driving form, they can be divided into
non-powered
Roller conveyors,
power
roller conveyors.
Power Roller Conveyor
Roller conveyor encompasses many designs for a wide variety of applications. Roller conveyor can be used to simply transport product from point A to B. This is commonly referred to as live roller conveyor. Roller conveyor can also be used to accumulate product with minimum or zero pressure. It can also be used to convey large heavy loads such as pallets with chain driven roller.
Powerless Conveyor
Non-powered conveyors, commonly referred to as gravity conveyor, are an economical choice for unit handling. Loads are conveyed on rollers or skatewheels. These conveyors are usually installed with a 4 degree to 7 degree decline to allow the product to flow. Gravity conveyor is widely used within pick modules, work stations, and truck loading/unloading. Bastian Solutions has a wide variety of gravity conveyors that can be specified to meet your application.
Application
Packing & Delivery
Our pictures are real shots of the factory.
Order our products to check the factory and provide real shot videos.
