Quick Details
-
MF:
-
N/A
-
EINECS No.:
-
N/A
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Juli
-
Model Number:
-
frp 035
-
Dimensions:
-
2mm to 50mm and according to you requirement
-
Color:
-
red, yellow, white, black,etc
-
Material:
-
Fiberglass and Epoxy resin
-
Length:
-
Any length can be cut according to your requirements
-
Size:
-
Various specifciations.As per consumers' request
-
Performance:
-
Fiberglass product Non-conductive,Design Flexibility
-
Certification:
-
ISO9001:2000
-
Cost:
-
Low cost
-
Place of origin:
-
China
-
Feature:
-
Light weight
Quick Details
-
CAS No.:
-
N/A
-
Purity:
-
99%
-
Other Names:
-
fiberglass tube/rod
-
MF:
-
N/A
-
EINECS No.:
-
N/A
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Juli
-
Model Number:
-
frp 035
-
Dimensions:
-
2mm to 50mm and according to you requirement
-
Color:
-
red, yellow, white, black,etc
-
Material:
-
Fiberglass and Epoxy resin
-
Length:
-
Any length can be cut according to your requirements
-
Size:
-
Various specifciations.As per consumers' request
-
Performance:
-
Fiberglass product Non-conductive,Design Flexibility
-
Certification:
-
ISO9001:2000
-
Cost:
-
Low cost
-
Place of origin:
-
China
-
Feature:
-
Light weight
FRP pultruded fiberglass rod
Feature:
1.corrosion resistant
2.lightweight,
3.extremely strong and durable
4.mainly used for power&chemical plant
5.high strehght
6.good flexibility
7.aging resistant
8.corrosion resistant
FRP pultruded fiberglass rod
1 made of fiberglass or ECR-fiberglass (FRP/GRP) and epoxy resin
2.high mechanical strength
1.Description: FRP pultruded fiberglass rod is made of fiberglass or ECR-fiberglass (FRP/GRP) and epoxy resin, With high mechanical strength and electrical properties, light weight, high intensity, corrosion and high temperature resistance, age resistance, used for composite insulator core, pocelain insulator, high voltage line, cable jackets, cable cores (bearing tensile stress) and other related area.
2. Specifications:
Diameter: 8-300 mm
Length: 1000mm, 2000 mm, and according to request.
3. standard color: yellow, green ,black,red, light green.brown,orange.We can also offer other colors according to the requirements of customers .
4. Applications:
The pultruded round rod offers a unique combination of chemical resistance, size stability, high strength, and thermal/electric non-conductivity. So the pultruded round rod can be used in the fields of chemical anti-corrosion, construction, electric insulation, power development and telecommunications etc.
We Can Supply Strong FRP Pultrusion Fiberglass Duct Rod for Insulation
FRP pultruded fiberglass rod,FRP pultruded fiberglass rod,FRP pultruded fiberglass rod Fiberglass Rod , Solid Fiberglass Rods,Flexible Fiberglass Rod,Fiberglass Insulation Rod Pictures, polyester resin for fiberglass,polyester resin for fiberglass,polyester resin for fiberglass
Still many styles, pls contact us for more details
ROD size list
| item | Size(mm) | Weight(kg/m) | |
|
3 | 0.014 | |
| 6.9 | 0.077 | ||
| 7.3 | 0.083 | ||
| 7.9 | 0.1 | ||
| 8.5 | 0.116 | ||
| 9.5 | 0.145 | ||
| 10 | 0.16 | ||
| 11 | 0.194 | ||
| 12 | 0.231 | ||
| 12.7 | 0.259 | ||
| 16 | 0.395 | ||
| 18 | 0.51 | ||
| 20 | 0.628 | ||
| 22 | 0.771 | ||
| 24 | 0.9 | ||
| 25 | 0.95 | ||
| 35 | 1.92 |
specifications of Epoxy Fiberglass Insulator Rod
|
NO |
PARAMETER |
unit |
indicators |
|
1 |
Density(20±2°C) |
g/cm3 |
≥2.0 |
|
2 |
Water Absorption rate(at 20±2°C,24h) |
% |
≤0.05 |
|
3 |
Tensile Strength |
Mpa |
≥1200 |
|
4 |
Bending Strength |
Mpa |
900 |
|
5 |
dye penetration test |
min |
≥15 |
|
6 |
water diffusion test(1% NaCI boiling for 100h, 12kv,1min) |
µa |
≤200 |
|
7 |
Volume resistivity(140°C,96h) |
Ω.M |
10*1010 |
|
8 |
DC breakdown(10min) |
KV |
60kv |
|
9 |
Lightning impulse withstand voltage(10kv,10mm) |
times |
8 |
|
10 |
Bending Strength at heating conditions |
Mpa/150°C |
310 |
|
11 |
ECR rod stress corrosion(1mo1/1HNO3,at 67%stress) |
h |
≥96 |
Our Epoxy Fiberglass Duct Rod is great performence and appearence.We will replyyou asap if you are interested in our product.
