Quick Details
-
Model Number:
-
black iron wire
-
Product name:
-
Black Iron Wire
-
Material:
-
Low Carbon Steel Q195
-
Application:
-
Building Material
-
Surface:
-
Black
-
Color:
-
Balck
-
Coil weight:
-
1kg-1000kgs/coil
-
Wire Gauge:
-
BWG8-BWG24
-
Package:
-
Customers Request
-
Packing:
-
Woven Bag
-
Wire diameter:
-
BWG26-BWG8(0.45mm-4mm)
Quick Details
-
Function:
-
Binding Wire
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
orientaiflourish
-
Model Number:
-
black iron wire
-
Product name:
-
Black Iron Wire
-
Material:
-
Low Carbon Steel Q195
-
Application:
-
Building Material
-
Surface:
-
Black
-
Color:
-
Balck
-
Coil weight:
-
1kg-1000kgs/coil
-
Wire Gauge:
-
BWG8-BWG24
-
Package:
-
Customers Request
-
Packing:
-
Woven Bag
-
Wire diameter:
-
BWG26-BWG8(0.45mm-4mm)
Specification
|
Gauge
|
SWG
|
|
BWG
|
|
AWG
|
|
|||
|
|
Inch
|
mm
|
Inch
|
mm
|
Inch
|
mm
|
|||
|
8
|
0.16
|
4.046
|
0.165
|
4.191
|
0.1285
|
3.264
|
|||
|
9
|
0.144
|
3.658
|
0.148
|
3.759
|
0.1144
|
2.906
|
|||
|
10
|
0.128
|
3.215
|
0.134
|
3.404
|
0.1019
|
2.588
|
|||
|
11
|
0.116
|
2.946
|
0.12
|
3.048
|
0.0907
|
2.305
|
|||
|
12
|
0.104
|
2.642
|
0.109
|
2.769
|
0.0808
|
2.053
|
|||
|
13
|
0.092
|
2.337
|
0.095
|
2.413
|
0.072
|
1.828
|
|||
|
14
|
0.08
|
2.032
|
0.083
|
2.108
|
0.0641
|
1.628
|
|||
|
15
|
0.072
|
1.829
|
0.072
|
1.829
|
0.0571
|
1.45
|
|||
|
16
|
0.064
|
1.626
|
0.065
|
1.651
|
0.0508
|
1.291
|
|||
|
17
|
0.056
|
1.422
|
0.058
|
1.473
|
0.0453
|
1.15
|
|||
|
18
|
0.048
|
1.219
|
0.049
|
1.245
|
0.0403
|
1.024
|
|||
|
19
|
0.04
|
1.016
|
0.042
|
1.067
|
0.0359
|
0.912
|
|||
|
20
|
0.036
|
0.914
|
0.035
|
0.839
|
0.032
|
0.812
|
|||
|
21
|
0.032
|
0.813
|
0.032
|
0.831
|
0.0285
|
0.723
|
|||
|
22
|
0.028
|
0.711
|
0.028
|
0.711
|
0.02535
|
0.644
|
|||
|
23
|
0.024
|
0.61
|
0.025
|
0.635
|
0.02256
|
0.573
|
|||
|
24
|
0.022
|
0.559
|
0.022
|
0.559
|
0.02011
|
0.511
|
|||
|
25
|
0.02
|
0.508
|
0.02
|
0.508
|
0.01791
|
0.455
|
|||
|
26
|
0.018
|
0.457
|
0.018
|
0.457
|
0.01594
|
0.405
|
|||
|
Name
|
Black iron wire
|
|
Diameter
|
0.3-7mm
|
|
Application
|
Building Material Etc
|
|
Tensile strength
|
350-550N/mm2
|
|
Coil weight
|
1-500KG
|
|
Certificate
|
CE ISO Etc
|
|
Packing
|
1.LCL: packed with plastic film then on the pallets
2.FCL: Nude packing 3.Other special package according to customers' requirements. |
|
Payment Terms
|
T/T( 30% deposit , 70% balance against BL copy ) , or L/C
|
The black iron wire is one of the best construction binding wire by its low price,and good flexibility.
Black iron wire is made of low carbon steel wire, through wire drawing, acid washing, and rust removing, annealing and coiling.
It mainly used in construction, handicrafts, woven wire mesh, express way fencing mesh, packaging of products and other daily uses.
Tensile strength: 350-550N/mm2
Elongation: 10%
Electro galvanized iron wire
Zinc coating: 10-18g/m2
Tensile strength: 350-550N/mm2
Elongation: 10%
Application
GALVANIZED GI WIRE APPLICATION
1. General purpose iron wire rope : used in various ranges.
2. Iron wire rope for elevator: it is used in elevator equipmentcarrying people and things in high-rise buildings. It is required to have a compact and soft structure and small structural
elongation. It usually adopts 8-strand structure.
elongation. It usually adopts 8-strand structure.
3. Aviation wire rope: it is used for aircraft aerial rope or operation aerialrope, which is required to have high fatigue performance and corrosion resistance.
4. Iron wire rope for petroleum: strong bearing capacity and corrosion resistance.
5.Iron wire rope for aerial cableway and cable car: it is used for air transportation track.With cable car as the means of transportation, the steel wire rope is required to have a large safety factor, corrosion resistance and smooth surface.
6. Hoisting wire rope: it is required that the wire rope has high tensile strength, good flexibility, no rotation, distortion fatigue resistance and no looseness.
7. Fishing wire rope: it is used for trawling, fixed net, rolling net, etc. it works in rivers, lakes and sea water environment.It is required to have good corrosion resistance and flexibility.
8. Iron wire rope for mine hoisting.
9. Iron wire rope for tape.
10. Balance wire rope.
Packing & Delivery
We all use seaworthy packing with waterproof and corrosion resistant.
We deliver goods to the ports by truck and rail. By sea or air to the port of destination.Other delivery methods and place of delivery are possible by agreement.
