- Product Details
- {{item.text}}
Quick Details
-
Application:
-
Other
-
Design Style:
-
Contemporary
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
UNQ
-
Model Number:
-
polycarbonate corrugated sheet SZ2801
-
Type:
-
Sun Sheets & PC Embossed Sheets
-
Name:
-
Polycarbonate Corrugated Sheet
-
Color:
-
Lake blue, blue, green etc.
-
Material:
-
Polycarbonate
-
Thickness:
-
0.8mm~3.0mm
-
Size:
-
2100*5800mm/6000mm/11800mm/12000mm
-
Item:
-
Polycarbonate Corrugated Roofing Sheet
-
Product name:
-
Pc Corrugated Sheet Used Commercial Greenhouses
Quick Details
-
Warranty:
-
More than 5 years
-
After-sale Service:
-
Online technical support, Onsite Installation, Onsite Training, Onsite Inspection
-
Project Solution Capability:
-
graphic design, 3D model design
-
Application:
-
Other
-
Design Style:
-
Contemporary
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
UNQ
-
Model Number:
-
polycarbonate corrugated sheet SZ2801
-
Type:
-
Sun Sheets & PC Embossed Sheets
-
Name:
-
Polycarbonate Corrugated Sheet
-
Color:
-
Lake blue, blue, green etc.
-
Material:
-
Polycarbonate
-
Thickness:
-
0.8mm~3.0mm
-
Size:
-
2100*5800mm/6000mm/11800mm/12000mm
-
Item:
-
Polycarbonate Corrugated Roofing Sheet
-
Product name:
-
Pc Corrugated Sheet Used Commercial Greenhouses
Products Description
1. Using exquisite craftsmanship and strict inspection standards, make the tinting of polycarbonate sheet more uniform.
2. The normal thickness of anti-UV layer is 50 micron. If for special projects, we can do 80 micron, or even thicker.
3. For polycarbonate solid sheet, the thickest we can do 20mm at present. Can meet your requirement for different situations.
4. To prevent pc sheets fade easily and extend service life, we use color master-batch instead of toner.
5. For raw material, we all use 100% virgin polycarbonate material. This helps us produce very high quality pc sheet without defects, and helps us gain good reputation among customers.
2. The normal thickness of anti-UV layer is 50 micron. If for special projects, we can do 80 micron, or even thicker.
3. For polycarbonate solid sheet, the thickest we can do 20mm at present. Can meet your requirement for different situations.
4. To prevent pc sheets fade easily and extend service life, we use color master-batch instead of toner.
5. For raw material, we all use 100% virgin polycarbonate material. This helps us produce very high quality pc sheet without defects, and helps us gain good reputation among customers.
Solid Polycarbonate Sheet Specifications:
|
Thickness (mm)
|
Weight (kg/m2)
|
Mini-bending radius
(mm)
|
Width
(m)
|
Length
(m)
|
Colour
|
|
1.1
|
1.32
|
234
|
1.22-2.1
|
no limited, It can be rolled like 30 meter
|
Clear/Green/Blue /Brown/Opal/Red /Yellow, or customize
|
|
2
|
2.4
|
360
|
1.22-2.1
|
|
|
|
3
|
3.6
|
540
|
1.22-2.1
|
|
|
|
4
|
4.8
|
720
|
1.22-2.1
|
|
|
|
5
|
6
|
900
|
1.22-2.1
|
≤5.8m for 20ft,
≤11.8m for 40ft
|
|
|
6
|
7.3
|
1080
|
1.22-2.1
|
|
|
|
8
|
9.6
|
1440
|
1.22-2.1
|
|
|
Solid Polycarbonate Sheet
Techniacal Data:
|
Impact strength
|
850J/m
impact strength of solid PC sheets is 250 times of glass,
20-30 times of PMMA sheet
|
|
Light transmission
|
80%-90% for different thickness of clear color
|
|
UV resistance
|
50μm UV layer, can filter 99% ultraviolet radiation in sunlight
|
|
Coefficient of thermal expansion
|
0.065 mm/m°c
|
|
Service temperature
|
-40°c to 120°c
|
|
Heat conductivity
|
2.3-3.9 W/m2 °c
|
|
Tensile strength
|
>60N/mm2
|
|
Flexural strength
|
100N/mm2
|
|
Tensile street at break
|
>65mPa
|
|
Heat deflection temperature
|
140°c
|
|
Soundproof index
|
4mm thickness--27dB,5mm--28dB,6mm--29dB
|
