1. LCD Display
2. Status indicator
3. Charging indicator
4. Fault display
5. Function buttons
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Sacolar
-
Model Number:
-
Sunicorn MHP
-
Output Frequency:
-
50Hz/60Hz
-
Size:
-
Based
-
Weight:
-
5-18KG
-
Output Power:
-
1 - 200KW
-
Color:
-
Red, Silver, Blue, or customized
-
Parallel Inverters:
-
Optional
-
Monitoring Access:
-
Optional
-
Certificate:
-
CE
Quick Details
-
Output Current:
-
Load
-
Network:
-
GPRS, WIFI
-
Customized support:
-
OEM
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Sacolar
-
Model Number:
-
Sunicorn MHP
-
Output Frequency:
-
50Hz/60Hz
-
Size:
-
Based
-
Weight:
-
5-18KG
-
Output Power:
-
1 - 200KW
-
Color:
-
Red, Silver, Blue, or customized
-
Parallel Inverters:
-
Optional
-
Monitoring Access:
-
Optional
-
Certificate:
-
CE
Product Introduction
Sunicorn MHP series off grid solar inverter is integrated with a MPPT solar charge controller, a high frequency pure sine wave inverter and a UPS function module in one machine, which is perfect for off grid backup power and self-consumption applications.
Sunicorn series inverter is available for motoring access. Customer can monitor the PV system on web or cellphone anytime anywhere.
Product Features
Rated power 2KW to 5KW
MPPT solar charge controller to maximize the solar output
High frequency inverter with small size and light weight
Pure sine wave AC output
Overload, short circuit and deep discharge protection
Configurable AC/ solar input priority via LCD setting
Compatible to mains voltage or generator power
WIFI/ GPRS remote monitoring (optional)
Parallel operation for Sunicorn MHP 4KW/5KW
System matching recommendation:
Product Overview
DiSPLAY INFOMATION
BOTTOM PANEL
6. AC input 7. WiFi/GPRS communication port
8. USB port
9. Dry contact
10. PV input 11. Power on/off switch
12. Battery input
13. Parallel communication ports (only for parallel model)
14. Current sharing ports (only for parallel model)
15. AC output 16. Circuit breaker
System Connection
Sunicorn series parallel connecting:
Specification
Sunicorn MHP series, with MPPT controller:
|
Model
|
Sunicorn MHP-2KW
|
Sunicorn MHP-3KW
|
Sunicorn MHP-4KW
|
Sunicorn MHP-5KW
|
|
Input / Output Voltage
|
DC 24V / AC 220V
|
DC 24V / AC 220V
|
DC 48V / AC 220V
|
DC 48V / AC 220V
|
|
Max. PV Power
|
1000W
|
1000W
|
4000W
|
4000W
|
|
Max. PV Charge Current
|
40A
|
40A
|
80A
|
80A
|
|
AC Charge Current
|
30A
|
30A
|
60A
|
60A
|
Sunicorn HP series, with PWM controller:
|
Model
|
Sunicorn HP-2KW
|
Sunicorn HP-3KW
|
Sunicorn HP-4KW
|
Sunicorn HP-5KW
|
|
Input / Output Voltage
|
DC 24V / AC 220V
|
DC 24V / AC 220V
|
DC 48V / AC 220V
|
DC 48V / AC 220V
|
|
Max. PV Power
|
1200W
|
1200W
|
2400W
|
2400W
|
|
Max. PV Charge Current
|
50A
|
50A
|
50A
|
50A
|
|
AC Charge Current
|
30A
|
60A
|
60A
|
60A
|
Product Processing
With a assembly of the top talents in the industry
One of the most intelligent and automatic inverter production lines in China
Production capacity over 100, 000 pieces a year
