Quick Details
-
Brand Name:
-
DAHAN
-
Weight:
-
2040 KG
-
Product name:
-
linear vibrating feeder sieve conveyor
-
Type:
-
Electric Medium and short distance transportation
-
Function:
-
Conveying Feeding Equipment
-
Frame Material:
-
Carbon Steel/Stainless Steel
-
After-sales Service Provided:
-
Video Technical Support
-
After Warranty Service:
-
Video Technical Support Online Support
-
Customized:
-
Support
-
Packing:
-
Wooden Box
-
Feeding materials:
-
Small piece Granular Powdery
Quick Details
-
Application:
-
smallmassive, granular and powder materials, Mining Feed
-
Capacity(t/h):
-
80-120t/h
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
DAHAN
-
Weight:
-
2040 KG
-
Product name:
-
linear vibrating feeder sieve conveyor
-
Type:
-
Electric Medium and short distance transportation
-
Function:
-
Conveying Feeding Equipment
-
Frame Material:
-
Carbon Steel/Stainless Steel
-
After-sales Service Provided:
-
Video Technical Support
-
After Warranty Service:
-
Video Technical Support Online Support
-
Customized:
-
Support
-
Packing:
-
Wooden Box
-
Feeding materials:
-
Small piece Granular Powdery
Product Description
DZC vibration conveyor feeder is an important inertia conveyor. Simple structure, diverse form and size ,to meet different environmental requirements, are widely used in various industries for a variety of small massive, granular and powder materials short-range transport.DZC vibration conveyor feeder is made of vibration motor or vibrator, carrier, damping bearing, bearing foundation and related accessories and other components.
Features
The conveyor carrier may are processed in the form of a U-shaped groove and a tubular structure using of different materials, etc., and can be made into the seals required to open or closed type, in order to meet the different processes ; Because the device is a metal carrier body parts and lubrication points away from the material, so that the machine can not only transport all kinds of normal temperature, ordinary materials, and can transport a lot of hot, toxic and other unconventional materials; such as carrier implementation of special processingjn the course of transmission can be achieved material screening, drying, heating, cooling and other process requirements.
Technical parameters
|
Model
|
Width(mm)
|
Power（KW）
|
Angle(°)
|
Capacity(T/H)
|
Weight(kg)
|
|
DZC30250
|
300
|
0.75
|
0～5
|
15-30
|
325
|
|
DZC30300
|
300
|
0.75
|
|
15-25
|
390
|
|
DZC50350
|
500
|
1.5
|
|
30-50
|
515
|
|
DZC50400
|
500
|
1.5
|
|
30-40
|
590
|
|
DZC50450
|
500
|
1.5
|
|
25-30
|
665
|
|
DZC50500
|
500
|
3
|
|
50-80
|
820
|
|
DZC50550
|
500
|
3
|
|
40-70
|
900
|
|
DZC50600
|
500
|
3
|
|
30-60
|
980
|
|
DZC50650
|
500
|
3
|
|
30-50
|
1060
|
|
DZC50700
|
500
|
3
|
|
30-40
|
1140
|
|
DZC50750
|
500
|
3
|
|
20-30
|
1220
|
|
DZC70800
|
700
|
4.4
|
|
80-140
|
1800
|
|
DZC70850
|
700
|
4.4
|
|
80-130
|
1920
|
|
DZC70900
|
700
|
4.4
|
|
80-120
|
2040
|
|
DZC70950
|
700
|
4.4
|
|
70-110
|
2160
|
|
DZC701000
|
700
|
4.4
|
|
60-100
|
2280
|
Same Series Product Show
Welcome to customize.
