Quick Details
-
Voltage:
-
220V50HZ/380V50HZ
-
Rated Power:
-
100w
-
Dimension(L*W*H):
-
330*278*175CM
-
Weight (KG):
-
2000 KG
-
Year:
-
2021
-
Marketing Type:
-
Hot Product 2023
-
Core Components:
-
Plasma Power Source
-
Working size:
-
1500*3000
-
Working material:
-
Steel,aluminum,stainless steel
-
Z axis clearance:
-
100mm
-
Working material thickness:
-
0.5-30mm
-
Plasma Power:
-
HUAYUAN,Cut Master,Hyper Therm
-
Input current:
-
63A,85A,100A,120A, 160A 200A etc
-
Plasma Cutting accuracy:
-
+0.5mm
-
Repeatability:
-
0.05mm
-
Cutting speed:
-
0-8m/min
-
Input voltage:
-
380V 3Ph or 220V,3Ph (Customized for you)
Quick Details
-
Dimensions:
-
1530
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
VMADE
-
Voltage:
-
220V50HZ/380V50HZ
-
Rated Power:
-
100w
-
Dimension(L*W*H):
-
330*278*175CM
-
Weight (KG):
-
2000 KG
-
Year:
-
2021
-
Marketing Type:
-
Hot Product 2023
-
Core Components:
-
Plasma Power Source
-
Working size:
-
1500*3000
-
Working material:
-
Steel,aluminum,stainless steel
-
Z axis clearance:
-
100mm
-
Working material thickness:
-
0.5-30mm
-
Plasma Power:
-
HUAYUAN,Cut Master,Hyper Therm
-
Input current:
-
63A,85A,100A,120A, 160A 200A etc
-
Plasma Cutting accuracy:
-
+0.5mm
-
Repeatability:
-
0.05mm
-
Cutting speed:
-
0-8m/min
-
Input voltage:
-
380V 3Ph or 220V,3Ph (Customized for you)
1325/1530/1560/2030 Accurate Tools Plasma Cutter Machine CNC Plasma Cutting Machines
Application
Cheap CNC Plasma Cutting Machine Applications Industry:
Ship Building, Construction Equipment, Transport Equipment, Aerospace Industry, Bridge Building, military industrial, wind power, Structural Steel, Boiler containers, Agriculture Machinery, Chassis electrical cabinets, Elevator manufacturers, Textile Machinery, Environmental protection equipment, ect.
Cheap CNC Plasma Cutting Machine Applications Materials:
All kinds of metal materials such as steel, copper, aluminum and stainless steel can be processed. Applies to iron plate, aluminum plate, galvanized sheet, White Steel plate, Titanium plates, and so on like the sheet metal
Performance Characteristics
u Cutting speed is up to 18 meters per minute with an accuracy of ±0.3mm.
u The structure of the boring machine adopts a combination of rivet welding and assembly to prevent deformation of the body itself.
u The cutting port is small, tidy, and has no slag phenomenon, avoiding secondary dressing processing.
u The CNC system has high configuration, automatic arc ignition and stable performance. The success rate of arc ignition is more than 99%.
u Plasma power supply and cutting gun are equipped with domestic famous brands and manufacturers of many foreign patented technologies.
u It can be combined with other advertising equipment (blister machine, metal slotting machine, metal folding machine) to form metal craft font production and processing line.
u precision.Supports standard G code path files generated by software such as ARTCUT, CAXA, ARTCAM, TYPE3, etc., and supports DXF format files generated by other software. The control system uses U disk exchange processing
|
Model |
VLP1530 |
|
Working area |
1500mm*3000mm |
|
Cutting Speed |
0-8m/min |
|
Moving Speed |
0-50m/min |
|
Cutting precision |
±0.5mm |
|
Repeat cutting precision |
0.05mm |
|
Plasma Generator |
Huayuan 120ah |
|
Machine total Power |
8.5kw |
|
Input Voltage |
3 phase 380V |
|
Motor & Driver |
Stepper motor |
|
Control system |
STARTFIRE control system |
|
Machine drawing Software |
FASTCAM software /Ucancam |
|
Power Frequency |
50HZ |
|
Files Transfer |
USB Interface |
|
Arc |
Untouched arc striking |
