Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
ZHONGCAN
-
Single Pulse Energy:
-
Continuous
-
Pulse Width:
-
Continuous
-
Wavelength:
-
1080nm
-
Focal Spot Diameter:
-
5mm
-
Dimensions:
-
55*90*103cm
-
Weight (KG):
-
160 KG
-
Marketing Type:
-
New Product 2023
-
Warranty of core components:
-
3 Years
-
Cooling System:
-
Water-Cooling
-
Language:
-
English/Chinese/Spanish/Korean/Russian/German/Others
-
Voltage:
-
220V/380V/Customized
-
Application:
-
welding cutting cleaning metal
-
Power:
-
1000W /1500W/2000W/3000W
Quick Details
-
Max. Output Power:
-
3000W
-
Usage:
-
welding cutting cleaning metal
-
Laser Source Brand:
-
MAX/Raycus/RECI/JPT
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
ZHONGCAN
-
Single Pulse Energy:
-
Continuous
-
Pulse Width:
-
Continuous
-
Wavelength:
-
1080nm
-
Focal Spot Diameter:
-
5mm
-
Dimensions:
-
55*90*103cm
-
Weight (KG):
-
160 KG
-
Marketing Type:
-
New Product 2023
-
Warranty of core components:
-
3 Years
-
Cooling System:
-
Water-Cooling
-
Language:
-
English/Chinese/Spanish/Korean/Russian/German/Others
-
Voltage:
-
220V/380V/Customized
-
Application:
-
welding cutting cleaning metal
-
Power:
-
1000W /1500W/2000W/3000W
|
Laser Type
|
Fiber Laser
|
|
Laser Source
|
MAX/Raycus/RECI
|
|
Laser Power
|
1000W/1500W/2000W/3000W
|
|
Laser Wavelength
|
1080±10nm
|
|
Output power Instability
|
＜2%
|
|
Output Power Tunability
|
10-100%
|
|
Fiber Laser Optic Length
|
standard 10m / 15m / 20m
|
|
Cooling Way
|
Water-cooling
|
|
Cooling medium
|
purified water, distilled water, high-purity water
|
|
Tank capacity
|
13L/16L
|
|
Laser Head
|
Gefassst SUP/Relfar/QiLin
|
|
Laser System
|
Gefassst SUP/Relfar/QiLin
|
|
Wobble Width
|
0-6 mm
|
|
Spot Size
|
﹤5mm
|
|
Welding Mode
|
straight line，fish scale，spot
|
|
Auxiliary Gas
|
Nitrogen/Argon
|
|
Cleaning Width
|
40mm
|
|
Voltage
|
220V/380V/Customized
|
|
Working Environment Requirements
|
10℃~40℃, humidity﹤70%
|
Laser Source
We use MAX/RECI/Raycus world-famous and top quality laser sourc, excellent beam quality. RECI with special after-sales service 1- year global warranty.
Welding Gun
SUP/Gefasst 3 in 1 version, support welding cleaning and cutting. It is ranked top in Chinese welding gun with high quality.
Control System with Touch Screen
SUP/Gefasst newest version, easy to operate, we will set parameters well and you only need to modify few parameters, supports process storage and supports 19 languages. We can set your language for you.
S&A/Hanli Chiller
We use the most professional chillers. lt is dedicated to laser welding the temperature control accuracy reaches 0.5 ℃, and the dual temperature design can satisfy the cooling of the laser source and the welding gun at the same time
Automatic wire feeder
lt is used for replenishing welding wire automatically, with an independent touch screen with 19 languages, is more convenient to control wire feeding (other wire feeder you need to operate on the touch screen of the machine)
Accessories
our company provides exclusive consumables (protective lens and welding nozzles) and tools for free (They worth about 200usd. Many supplier do not provide these or charge you)
send inquiry to get detailed offer!
Our company Zhongcan Technology Co., Ltd is a professional laser equipment manufacturer in China. we were established in 2011 and covers an area of 2500 square meters, with complete production line and team of experienced technical, sales, and after-sales. Main products include laser welding machines, laser marking machines, laser cleaning machines, laser cutting machines，laser engraving machines, etc. You can customize products here. Zhongcan products are made according to the USA and Europe quality standards, having been exported to over 70 countries and we received many praise from all over the world！
Zhongcan always adheres to provides customers with reliable products and considerate service. We welcome friends from all over the world to contact us and seek opportunities for win-win cooperation.
FAQ：
Q:
Which model should I choose?
Please tell me your Materials and cleaning demand, we will help you.Example: I want to clean rust on the boat, send to XX
address...
Q: Are there consumables?
Protective lenses are consumables, we will give you 1-year consumption, you can contact us to buy more.
Q: What is the lead time?
Usually 2-5 working days after receiving the payment.
Customized models 12-15 days.
Q: Shipping method?
by sea, air, express, truck, or rail.
Shipping to port, airport, or door-to-door delivery.
Q: What about wholesale price?
If you are a wholesaler, distributor, or agent, please contact us to obtain the wholesale price
