Quick Details
-
Tolerance:
-
±1%
-
Invoicing:
-
by actual weight
-
Place of Origin:
-
China
-
Brand Name:
-
ts
-
Product name:
-
Galvanized Hot Cold Rolled C U Z Channel Steel Price
-
zinc coating:
-
galvanized 20-700g/m2
-
Length:
-
1-12m or Customer customization
-
Thickness:
-
0.8mm-20mm
-
Usage:
-
Commercial Buildings
-
Technique:
-
Cold Rolled Hot Rolled
Quick Details
-
Standard:
-
AiSi, ASTM, DIN, GB, JIS, BS
-
Grade:
-
Q195/Q235/Q345/304/316L/Other Metal Materials, Q195 , Q235, Q345, ss400, A36
-
Shape:
-
U Channel C Channel Z Channel
-
Tolerance:
-
±1%
-
Invoicing:
-
by actual weight
-
Place of Origin:
-
China
-
Brand Name:
-
ts
-
Product name:
-
Galvanized Hot Cold Rolled C U Z Channel Steel Price
-
zinc coating:
-
galvanized 20-700g/m2
-
Length:
-
1-12m or Customer customization
-
Thickness:
-
0.8mm-20mm
-
Usage:
-
Commercial Buildings
-
Technique:
-
Cold Rolled Hot Rolled
China Hot Dip Cold Roll Galvanized Steel C Z Channel Steel Purlins For Structural U Channel
price per meter
STEEL CHANNEL BAR IS OUR FACTORY MAIN PRODUCT, PLEASE GIVE US A CHANCE. LET'S SHOW OUR QUALITY AND PRICE FOR YOUR REFERENCE.
|
Production Name
|
Galvanized Channel Steel
|
|
Standard
|
ASME, ASTM, EN, BS, GB, DIN, JIS, etc
|
|
Production Size
|
As required
|
|
Material Grade
|
Q195 , Q235, Q345, ss400, A36 DX51D+Z DX52D+Z DX53D+Z DX54D+Z DX56D+Z DX57D+Z DC51D+Z SGCC SGCD S220GD+Z S250GD+Z S280GD+Z S320GD+Z S350GD+Z S550GD+Z G350 G450
G550 etc. |
|
Zinc Coating
|
20-600g/m2
|
|
Package
|
As per our standard or clients' request
|
|
Delivery Time
|
5~7 days after deposit
|
|
Productivity
|
3000 Ton Per Month
|
|
Application
|
Construction, machinery, coal mine, chemical industry, electric power, railway vehicle, automobile industry, etc.
|
|
Sample
|
Free Sample
|
|
Chinese standard U Channel Size
|
|
|
|
|
|
|||||
|
Size(MM)
|
Model
|
Weight(Kg/m)
|
Size(MM)
|
Model
|
Weight(Kg/m)
|
|||||
|
50*37*4.5
|
5#
|
5.44
|
240*78*7
|
24#A
|
26.86
|
|||||
|
63*40*4.8
|
6.3#
|
6.635
|
240*80*9
|
24#B
|
30.638
|
|||||
|
65*40*4.8
|
6.5#
|
6.7
|
250*78*7
|
25#A
|
27.41
|
|||||
|
80*43*5
|
8#
|
8.045
|
250*80*9
|
25#B
|
31.335
|
|||||
|
100*48*5.3
|
10#
|
10.007
|
270*82*7.5
|
27#A
|
30.838
|
|||||
|
120*53*5.5
|
12#
|
12.6
|
270*84*9.5
|
27#B
|
35.077
|
|||||
|
126*53*5.5
|
12.6#
|
12.37
|
280*82*7.5
|
28#A
|
31.427
|
|||||
|
140*58*6
|
14#A
|
14.53
|
280*84*9.5
|
28#B
|
35.823
|
|||||
|
140*60*8
|
14#B
|
16.73
|
300*85*7.5
|
30#A
|
34.463
|
|||||
|
160*63*6.5
|
16#A
|
17.23
|
300*87*9.5
|
30#B
|
39.173
|
|||||
|
160*65*8.5
|
16#B
|
19.755
|
320*88*8
|
32#A
|
38.083
|
|||||
|
180*68*7
|
18#A
|
20.17
|
320*90*10
|
32#B
|
43.107
|
|||||
|
180*70*9
|
18#B
|
23
|
360*96*9
|
36#A
|
47.814
|
|||||
|
200*73*7
|
20#A
|
22.637
|
360*98*11
|
36#B
|
53.466
|
|||||
|
200*75*9
|
20#B
|
25.777
|
400*100*10.5
|
40#A
|
58.928
|
|||||
|
220*77*7
|
22#A
|
24.999
|
400*102*12.5
|
40#B
|
65.208
|
|||||
|
220*79*9
|
22#B
|
28.453
|
|
|
|
|||||
Galvanized Channel Steel
China Hot Dip Cold Roll Galvanized Steel C Z Channel Steel Purlins For Structural U Channel
price per meter
Top Steel company have Photovoltaic support and all kinds shape Channel
Galvanized I Beam
Galvanized H Beam
Galvanized Angle Steel
Galvanized Flat Steel
Packaging & Shipping
20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
40ft HC:12032mm(Lengh)x2352mm(Width)x2698mm(High)
For 20feet container load 25tons-28tons.
For40feet container load 25tons-26tons.
Other options are available based on customer requests. Please discuss when placing orders. Top Steel company have the professional loading team, we will check the most economical way of loading according to your different length.
40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
40ft HC:12032mm(Lengh)x2352mm(Width)x2698mm(High)
For 20feet container load 25tons-28tons.
For40feet container load 25tons-26tons.
Other options are available based on customer requests. Please discuss when placing orders. Top Steel company have the professional loading team, we will check the most economical way of loading according to your different length.
China Hot Dip Cold Roll Galvanized Steel C Z Channel Steel Purlins For Structural U Channel
price per meter
Weihai Top Steel Co., Ltd. is located in the beautiful coastal city and world-class health city-Shandong Weihai.
Weihai Top Steel Co., Ltd. has exported steel products to over 40 countries in the world. Our products are marketed widely all
over the country and exported to North American, Europe, Middle East, South American, Southeast Asia, Africa, Australia etc and
get highly appreciated for our quality and service.
Top Steel would be based on the trustworthiness cooperation and quality first always. Our aim is “to reach customer satisfaction
with our best products”. According to clients’ requirements, We are the reliable manufacture and willing to work together with our
clients for a brilliant future.
Weihai Top Steel Co., Ltd is professional Chinese leading supplier of steel. Following are our main products:
1. Stainless steel strip,Coil,Sheet,Pipe,Round bar,Flat bar etc.
2. Galvanized steel strip,Coils, Sheet, PPGI,Corrugated sheets,etc.
3. Angle Bar,H beam,I beam,C channel U channel,Round bar,Flat Bar,etc.
4. Welded pipe,Seamless pipe, Square and rectangular pipe etc.
You are welcome to visit our factory and office anytime.
For more information please visit our official website: www.topsteelco.com
Weihai Top Steel Co., Ltd. has exported steel products to over 40 countries in the world. Our products are marketed widely all
over the country and exported to North American, Europe, Middle East, South American, Southeast Asia, Africa, Australia etc and
get highly appreciated for our quality and service.
Top Steel would be based on the trustworthiness cooperation and quality first always. Our aim is “to reach customer satisfaction
with our best products”. According to clients’ requirements, We are the reliable manufacture and willing to work together with our
clients for a brilliant future.
Weihai Top Steel Co., Ltd is professional Chinese leading supplier of steel. Following are our main products:
1. Stainless steel strip,Coil,Sheet,Pipe,Round bar,Flat bar etc.
2. Galvanized steel strip,Coils, Sheet, PPGI,Corrugated sheets,etc.
3. Angle Bar,H beam,I beam,C channel U channel,Round bar,Flat Bar,etc.
4. Welded pipe,Seamless pipe, Square and rectangular pipe etc.
You are welcome to visit our factory and office anytime.
For more information please visit our official website: www.topsteelco.com
FAQ
1, What is your time of making sample ?
Usually we will take 3-5 working days to make the sample.
2, What is your MOQ ?
Usually 20 feet containers (25 tons) for section steel.
3,What is your delivery time ?
For stocks, we can send the goods to loading port within 7 working days after receiving the deposit.
For production period, it usually needs about 15days- 25 working days after receiving the deposit.
4, What is your shipping port ?
Tianjin port, Shanghai,Qingdao port, Guangzhou etc.
5, What is your payment terms ?
Usually 30% deposit by T/T in advance and balance against copy of B/L or LC at sight.
