Quick Details
-
Rated Input Voltage:
-
220 V
-
Rated Output Voltage (MIG):
-
220 V
-
Welding Current/Voltage Range:
-
40% 160A 60% 124A 100% 72A
-
Wire Feeding Speed:
-
2.5 m/min
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
GREATEC
-
Dimensions:
-
480*203*368mm
-
Usage:
-
wedling low carbon steel..
-
Weight (KG):
-
12 KG
-
Year:
-
2020
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Input power voltage:
-
single phase 220V±15%
-
Rate output current(A):
-
160A
-
Rate output voltage(V):
-
MIG:16.5 MMA:22V
-
Welding thickness(mm):
-
≥0.8
-
Diameter of wire(mm):
-
0.8/1.0
-
Wire Feed Speed:
-
3-25S
-
Efficiency(%):
-
85
-
Base Metal::
-
Carbon Steel,Stainless Steel,Low-alloy Steel
-
Power(W):
-
MIG:5.7KVA MMA:6.2KVA
Quick Details
-
Wire Melting Type:
-
Spray Transfer
-
Max. Load Power Capacity:
-
6.2MIG:5.7KVAkVAkVAkVA MIG:KVAkVAkVAkVA
-
Rated Duty Cycle @40°C (MIG):
-
160A
-
Rated Input Voltage:
-
220 V
-
Rated Output Voltage (MIG):
-
220 V
-
Welding Current/Voltage Range:
-
40% 160A 60% 124A 100% 72A
-
Wire Feeding Speed:
-
2.5 m/min
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
GREATEC
-
Dimensions:
-
480*203*368mm
-
Usage:
-
wedling low carbon steel..
-
Weight (KG):
-
12 KG
-
Year:
-
2020
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Input power voltage:
-
single phase 220V±15%
-
Rate output current(A):
-
160A
-
Rate output voltage(V):
-
MIG:16.5 MMA:22V
-
Welding thickness(mm):
-
≥0.8
-
Diameter of wire(mm):
-
0.8/1.0
-
Wire Feed Speed:
-
3-25S
-
Efficiency(%):
-
85
-
Base Metal::
-
Carbon Steel,Stainless Steel,Low-alloy Steel
-
Power(W):
-
MIG:5.7KVA MMA:6.2KVA
<
|
Function and Feature
Machinery,Construction,Shipping,Automobiles,Bridges etc.
|
|
| Specifications: | |
| Parameter/Model | MIG-160 |
| Rated Input Current(A) | 29 |
| Input Voltage(V) | AC220±15% |
| Frequency(HZ) | 50/60 |
| Rated Input Power Capacity(KVA) | 4.6 |
| No-load Voltage(V) | 77 |
| Output Current Range (A) | 50-160 |
| Steel Thickness(mm) | 0.6-7 |
| Electrode Diameter(mm) | 0.8-1 |
| Diameter of the Wire Board (mm) | 270 |
| Wire Feed Speed | 3-25S |
| Pre-Flow | 0-2S |
| Power Factor | 0.93 |
| Duty Cycle(%) | MMA 60%,MIG 100% |
| Efficiency(%) | 85 |
| Insulation Grade | F |
| Housiing Protection Grade | IP21 |
| Dimension(MM) | 480*260*360 |
| New Weight(KG) | 32 |
| Base Metal: | Carbon Steel,Stainless Steel,Low-alloy Steel |
| Welding | CO2/MIG/MMA |
| Standard Accessories | 1.Torch MIG15 3M |
| 2.Earth Clamp Wire 16MM2 | |
| 3.Introduction Book | |
| 4.Hose Clamp*2 | |
| 5.Φ5 hexagon wrench | |
| 6.Quick Plug 35-50 | |
A:Our packing is double
B:And we also have
the tool box if you need pls contact us the ordinary package just carton package
show
like the first photo
Main Market:
North America, South America , Southeast Asia, Middle East, Africa
With standard spareparts: 2 Cable connectors(35-50), 1 screw driver
Supply:
1. OEM and ODMsevice offered, Machine Color
2. One Year Warranty.
3. Technical Support.
4. CE and CCC certificate
Strict Quality Control:
1.Our quality starts from the elemets. All parts are full new,refusing the used one .Our machine mainboard is made by ourself all the parts was in
strictly controling
.
2.Our quality controling systems are stopping the defect before packing; So we arrange at least 5 QC stations, In an assembling line ; then every tiny part in the charge of one worker ,even every screws should be marked
3.The scientific production management 6S , prevent the mistakes by human being at the upper limits
4. Our products are strictly tested 100% before delivery, and approved by CE.
Perfect after-service
1.Any defects ,you can check it firstly ,If you can find out the problems, we can send you the components to you
2.If you can`t find out the faults ,our engineer will provide the free guide on line free
3.If we can`t solve the problems by vedio ,Our engineers are possible to come to your countries
Remarks
1. You can print your logo on the products or color box
2. We can take the OEM orders
3. If you place a considerable quantity,we can give you a competitive price
4. We can match the parts for you
If you have browse this kind of welding machines,pls feel free to contact us
