Quick Details
-
Weight (KG):
-
180
-
Motor Power (kW):
-
3
-
overall dimensions:
-
850*550*880mm
-
work efficiency:
-
1440r/min
-
Voltage:
-
380V/220V
-
Bending Diameter:
-
4-28mm
Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Alec
-
Year:
-
2023
-
Weight (KG):
-
180
-
Motor Power (kW):
-
3
-
overall dimensions:
-
850*550*880mm
-
work efficiency:
-
1440r/min
-
Voltage:
-
380V/220V
-
Bending Diameter:
-
4-28mm
Products Description
1.Easy to use, good safety performance, standard angle, fast speed, light handling.
2.Easy to operate: only one person is required to work, no training is required, the machine will be operated when it is switched on.
3.The machine adopts two foot switches of 90 degrees and 135 degrees, the angle can be changed freely.
4. Angle standard: this machine adjusts the angle range between 0-365 degrees using adjustable angle bumper clamps, easy to adjust.
5. Fast speed, the machine's speed between 20-25 times per minute, bending hoops per hour in about 500.
3.The machine adopts two foot switches of 90 degrees and 135 degrees, the angle can be changed freely.
4. Angle standard: this machine adjusts the angle range between 0-365 degrees using adjustable angle bumper clamps, easy to adjust.
5. Fast speed, the machine's speed between 20-25 times per minute, bending hoops per hour in about 500.
Rebar bender is equipped with switches which can be preset to any angle between 0-180. With CNC control switch or 2 foot pedals switch, it can bend steel accurately, and complete multi-angle steel molding operations efficiently.
Details Images
Application
Product Model
|
Model
|
GF20
|
GF25
|
GF28
|
GF32
|
|||
|
Bending range(mm)
|
Round bar:4-20
Class bar: 4-18 |
Round bar:4-25
Class bar: 4-22 |
Round bar:4-28
Class bar: 4-25 |
Round bar:4-32
Class bar: 4-28 |
|||
|
Bending speed
|
12-20 times/min
|
14-22 times/min
|
12-20 times/min
|
15-20 times/min
|
|||
|
Motor power
|
2.2kw
|
3kw
|
3kw
|
3kw
|
|||
|
Input voltage
|
3 phase 220v/380v/415v or customized
|
|
|
|
|||
|
Motor speed
|
1440rpm
|
1440rpm
|
1440rpm
|
1440rpm
|
|||
|
Overall size(mm)
|
855*530*830
|
850*570*900
|
900*670*900
|
750*750*870
|
|||
|
weight(kg)
|
90
|
135
|
200
|
220
|
|||
|
Driving mode
|
gear
|
gear
|
gear
|
gear
|
|||
|
Operation mode
|
Travel switch control or digital control panel
|
|
|
|
|||
