Quick Details
-
Nature:
-
IPTV IRD
-
Input:
-
4 Channels Tuner
-
Output:
-
2 Gigabit or 100M self-adaptive IP
-
Tuner in standard:
-
DVB-S/S2
-
IP Protocol:
-
UDP/RTP
-
Configuration:
-
Web UI
-
Application:
-
digital CATV headend systems
-
MOQ:
-
1
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Dibviewolo
-
Model Number:
-
OTV-TP10A
-
Nature:
-
IPTV IRD
-
Input:
-
4 Channels Tuner
-
Output:
-
2 Gigabit or 100M self-adaptive IP
-
Tuner in standard:
-
DVB-S/S2
-
IP Protocol:
-
UDP/RTP
-
Configuration:
-
Web UI
-
Application:
-
digital CATV headend systems
-
MOQ:
-
1
Products Description
Overview
OTV-TP10A mini 4 Channels DVB-S/S2 professional Receiver, 4 Tuners ports per module. It is integrated with tuner demodulation,supports 4 channels of DVBS/S2 signals input and 2 channels of Gigabit Ethernet port IP output, then output the IP package through different IP address and ports. This is an ideal solution for environments where you have a large number of air Channel, and
widely used in IPTV System, Hotel, entertainment facilities, education broadcasting systems at schools and government buildings or any kinds of Source signals convert to Cable TV broadcast System, largely cost down the source gathering of Digital TV Broadcasting system and IPTV/OTT system which based on IP construction. Being the ideal multi-channel professional receiver used for FTA (free to air) IP signal source capture from digital tuner.
widely used in IPTV System, Hotel, entertainment facilities, education broadcasting systems at schools and government buildings or any kinds of Source signals convert to Cable TV broadcast System, largely cost down the source gathering of Digital TV Broadcasting system and IPTV/OTT system which based on IP construction. Being the ideal multi-channel professional receiver used for FTA (free to air) IP signal source capture from digital tuner.
Main Features
Tuner input: 4 DVBS/S2 signal input of independent high frequency tuner
IP stream output: MPTS and SPTS
Output IP protocol: UDP/RTP
Support 2 Gigabit or 100M self-adaptive IP output
Easy configuration & software upgrade by built-in Web UI
Low cost headend receiver for IPTV OTT System
Superior Shoulders and Excellent modulation
quality MER
Easy-to-Use System Management via Web
Low power consumption and high reliability with
MTBF(Mean Time Between Failure) ≦87600 Hours
Highly compact , High-Integrate
24*7 hours working stable, broadcasting quality
|
Specifications
|
|
|
|
|
||||
|
DVBS/S2
|
|
|
|
|
||||
|
Input Channels:4
Intermediate Frequency:950～2150MHz
Receiving Sensitivity:-80dBm |
|
|
|
|
||||
|
IP Output
|
|
|
|
|
||||
|
Network Interface:2 Gigabit or 100M self-adaptive
IP output Protocol:UDP/RTP IP Stream:SPTS，MPTS
|
|
|
|
|
||||
|
Power Supply
|
|
|
|
|
||||
|
Input Voltage:12V 1.5A
Power adaptor Max. Current:1A
|
|
|
|
|
||||
|
Physical Parameters
|
|
|
|
|
||||
|
Dimension:180*122*30mm
Operating Temperature/Humidity:-10℃～45℃、40%～70% Storage Temperature/Humidity:-40℃～70℃、40%～95% |
|
|
|
|
||||
Key Diagram or Application
