Quick Details
-
Application:
-
Lab/medical/testing Equipments
-
Keypad Button Material:
-
customized
-
Components:
-
LED, metal dome, connector and circuit or OEM
-
Dimension:
-
According to customers demand
-
Surface material:
-
PET(polyester),PC(polycarbonate) or OEM
-
Keys Options:
-
Tactile Keys/Non-tactile keys/OEM
-
Embossed type:
-
Pillow emboss, Dome emboss, Frame emboss
-
Cables:
-
The extension of circuit and communication with your device
-
circuitry option:
-
Silver printed/PCB circcuit board or OEM
-
Connector Tail:
-
Female/male connector/older Pins or OEM
-
Window:
-
Clear or Transparent
-
Surface:
-
Glossy or matte
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
MBR
-
Model Number:
-
OEM
-
Application:
-
Lab/medical/testing Equipments
-
Keypad Button Material:
-
customized
-
Components:
-
LED, metal dome, connector and circuit or OEM
-
Dimension:
-
According to customers demand
-
Surface material:
-
PET(polyester),PC(polycarbonate) or OEM
-
Keys Options:
-
Tactile Keys/Non-tactile keys/OEM
-
Embossed type:
-
Pillow emboss, Dome emboss, Frame emboss
-
Cables:
-
The extension of circuit and communication with your device
-
circuitry option:
-
Silver printed/PCB circcuit board or OEM
-
Connector Tail:
-
Female/male connector/older Pins or OEM
-
Window:
-
Clear or Transparent
-
Surface:
-
Glossy or matte
Graphic Overlay, also called Panel, is an important part of membrane switch, which can provide control function and beautiful modern appearance. It is made by printing graphics and text description on such materials as PVC, PC and PET. It is composed of multi-layer polyester and adhesive, which can be directly connected with electronic equipment through flexible circuit board connector. From material to material The main materials suitable for making membrane panel are: PVC (polyvinyl chloride), PC (polycarbonate) and PET (polyester), with the thickness of 0.125 \ 0.175 \ 0.25, and three surfaces of sand, matte and smooth. The physical and chemical properties of PC material are good, and it can adapt to many kinds of inks. It is the most common material for membrane switch panel. PC materials can be divided into sand surface and smooth surface. The reason for choosing sand surface materials is that the use of film switches is mostly electronic products, and the panel used as the control system does not want to be interfered by light, while the sand surface is only diffuse reflection, which will not produce bright reflection; at the same time, because the surface is disordered sand like, it has the function of masking scratches. In contrast, smooth materials do not have the above characteristics. But as a smooth material, if combined with the back printing, the color will appear more brilliant. In the case of strong decorative requirements and not frequently touched, the panel is often made of smooth materials, or due to the special needs of some display areas such as LCD, it is more favorable to choose smooth materials. The price of PVC
material is lower, about half of PC material. When producing popular civil products, PVC material can reduce production cost. At the same time, PVC material has good ductility, and can be used to cold press three-dimensional graphic
|
1. |
Components |
LED, metal dome, connector and circuit, all these can be designed and made according to customer requirements |
|
2. |
Dimension |
According to customers demand,OEM service |
|
3. |
Surface material |
PET(polyester),PC(polycarbonate) |
|
4. |
Embossed type |
|
|
5. |
|
For a tactile response and indicate the location of switches |
|
1. Tactile Keys : metal domes or poly domes |
||
|
2. Non-tactile keys : flat button, printed silver spot on the circuit |
||
|
6. |
The extension of circuit and communication with your device |
|
|
|
|
1. Silver printed conductive inks |
|
2.Copper etched circuit /Polyimide Kapton circuit ( FPC) |
||
|
3.PCB circcuit board |
||
|
|
|
1.Zero insertion force(ZIF) with 0.5MM ,1.0MM,1.25MM pitch |
|
2. Female connector with 2.54MM pitch |
||
|
3.Male connector |
||
|
4.Solder Pins |
||
|
9. |
Window |
Clear or Transparent |
|
10. |
Surface |
Glossy or matte |
