Quick Details
-
Tolerance:
-
±1%
-
Rail Heigth:
-
50.8mm/63.5mm/69.85mm/79.37mm
-
Bottom Width:
-
50.8mm/63.5mm/69.85mm/79.37mm
-
Web Thickness:
-
4.76mm/5.9mm/7.54mm/8.33mm
-
Head Width:
-
25.4mm/32.1mm/38.1mm/42.86mm
-
Length:
-
6-12m
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
ZHONGMEI
-
Model Number:
-
GB6KG/GB9KG/GB12KG/GB15KG/GB22KG/GB30KG
-
Weight:
-
5.98kg/m 8.94kg/m 12.2kg/m 15.2kg/m
-
Bolt Hole Diameter:
-
standard
-
Name of Commodity:
-
Light Steel Rail
-
Key words:
-
Light Steel Tracks
-
Standard of Products:
-
GB11264-89
-
Package:
-
Box
-
Service:
-
24-hour Service
-
Certificate:
-
CE ISO
-
name:
-
steel rail
-
Other name:
-
Railroal Track
-
Product name:
-
railway Light Rail
-
Keyword:
-
China Steel Light Rail
Quick Details
-
Standard:
-
GB
-
Grade:
-
Q235B/55Q
-
Type:
-
Light Rail
-
Tolerance:
-
±1%
-
Rail Heigth:
-
50.8mm/63.5mm/69.85mm/79.37mm
-
Bottom Width:
-
50.8mm/63.5mm/69.85mm/79.37mm
-
Web Thickness:
-
4.76mm/5.9mm/7.54mm/8.33mm
-
Head Width:
-
25.4mm/32.1mm/38.1mm/42.86mm
-
Length:
-
6-12m
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
ZHONGMEI
-
Model Number:
-
GB6KG/GB9KG/GB12KG/GB15KG/GB22KG/GB30KG
-
Weight:
-
5.98kg/m 8.94kg/m 12.2kg/m 15.2kg/m
-
Bolt Hole Diameter:
-
standard
-
Name of Commodity:
-
Light Steel Rail
-
Key words:
-
Light Steel Tracks
-
Standard of Products:
-
GB11264-89
-
Package:
-
Box
-
Service:
-
24-hour Service
-
Certificate:
-
CE ISO
-
name:
-
steel rail
-
Other name:
-
Railroal Track
-
Product name:
-
railway Light Rail
-
Keyword:
-
China Steel Light Rail
Welcome to China Coal Group!
Your Premier Destination for Steel H-Beams ☺
Are you in search of top-notch Steel H-Beams that combine exceptional quality, durability, and reliability?
Look no further!
At China Coal Group, we take immense pride in being a leading manufacturer of railway rails, catering to the diverse needs of railway infrastructure projects worldwide.
Products Description
Why Choose China Coal Group?
Uncompromising Quality:
We adhere to stringent quality standards to ensure that our railway rails meet or exceed industry requirements. Our rails undergo rigorous testing and inspection processes to guarantee their reliability, safety, and longevity.
Cutting-Edge Manufacturing:
Equipped with state-of-the-art facilities and advanced technologies, our production processes are streamlined for maximum efficiency and precision. We employ innovative techniques to create railway rails that excel in performance and structural integrity.
Customization Options:
We understand that every rail project is unique. That's why we offer a range of customization options to tailor our railway rails to your specific requirements. From different rail profiles and lengths to specialized coatings, we can accommodate your project's needs.
Expertise and Experience:
With years of experience in the railway industry, our team of skilled professionals possesses in-depth knowledge and expertise in rail manufacturing. We are committed to delivering products that not only meet but exceed your expectations.
Reliable Customer Support:
We believe in establishing long-lasting relationships with our clients. Our dedicated customer support team is always ready to assist you, providing prompt responses to inquiries, technical guidance, and after-sales support. Your satisfaction is our utmost priority.
Product Paramenters
|
THE LIST OF YYGT
|
|
|
|
|
|
|
||||||
|
Name of Commodity
|
Specificaton
|
Materials (Steel Grade)
|
Standard of Products
|
Theory Weight (kgs/M)
|
Length of Dimension (M)
|
Packed In Bundle With Iron Wire (pcs/bundle)
|
||||||
|
Light Rail
|
4kgs/m
|
Q235
|
Q/YG001-2014
|
4kgs/m
|
6,8
|
75
|
||||||
|
|
8kgs/m
|
Q235
|
Q/YG001-2014
|
8.42kgs/m
|
|
55
|
||||||
|
|
12kgs/m
|
Q235
|
GB11264-2012
|
12.2kgs/m
|
|
36
|
||||||
|
|
15kgs/m
|
Q235/55Q
|
GB11264-2012
|
15.2kgs/m
|
6,8,9,10
|
28
|
||||||
|
|
18kgs/m
|
Q235/55Q
|
Q/YG001-2014
|
18.06kgs/m
|
|
21
|
||||||
|
|
22kgs/m
|
Q235/55Q
|
GB11264-2012
|
22.3kgs/m
|
|
21
|
||||||
|
|
24kgs/m
|
Q235/55Q
|
Q/YG001-2014
|
24.46kgs/m
|
|
21
|
||||||
|
|
30kgs/m
|
Q235/55Q
|
GB11264-2014
|
30.1kgs/m
|
|
15
|
||||||
|
Heavy Rail
|
38kgs/m
|
U71Mn
|
GB2585-2007
|
38.733kgs/M
|
12,12.5
|
10
|
||||||
|
|
43kg/m
|
U71Mn
|
GB2585-2007
|
44.653kgs/M
|
|
10
|
||||||
|
|
50kgs/m
|
U71Mn
|
GB2585-2007
|
51.514kgs/M
|
|
10
|
||||||
|
|
|
45/50Mn
|
Q/YYG002-2008
|
31/34/36/39/41kgs/M
|
12,12.5
|
10
|
||||||
|
Crane Rail
|
QU70
|
U71Mn
|
YB/T5055-93
|
52.8kgs/m
|
12
|
10
|
||||||
|
|
QU80
|
|
YB/T5055-93
|
63.69kgs/m
|
|
10
|
||||||
|
|
QU100
|
|
YB/T5055-93
|
88.96kgs/m
|
|
5
|
||||||
|
|
QU120
|
|
YB/T5055-93
|
118.1kgs/m
|
|
5
|
||||||
