Quick Details
-
Size:
-
9500-13000*2500*3900mm
-
Place of Origin:
-
China
-
Product name:
-
Asphalt tanker
-
Dimension:
-
11880*2500*3700mm
-
Total Volume:
-
6000 Liters
-
Tanker shell:
-
5mm or 6 mm material optional
-
Bulkhead & end plate:
-
Material optional
-
Manhole cover:
-
Material optional
-
Number of compartments -:
-
Optional
-
Tire:
-
12.00R22.5/315 80R22.5/11.00R20/12.00R20
-
Axle:
-
3 Axles
-
King pin:
-
JOST 2.00 or 3.5 inch
Quick Details
-
Type:
-
Semi-Trailer
-
Max Payload:
-
40t
-
Brand Name:
-
YUETONG
-
Size:
-
9500-13000*2500*3900mm
-
Place of Origin:
-
China
-
Product name:
-
Asphalt tanker
-
Dimension:
-
11880*2500*3700mm
-
Total Volume:
-
6000 Liters
-
Tanker shell:
-
5mm or 6 mm material optional
-
Bulkhead & end plate:
-
Material optional
-
Manhole cover:
-
Material optional
-
Number of compartments -:
-
Optional
-
Tire:
-
12.00R22.5/315 80R22.5/11.00R20/12.00R20
-
Axle:
-
3 Axles
-
King pin:
-
JOST 2.00 or 3.5 inch
Products Description
|
Yuetong Automobile Industry (Tianjin) Co.,Ltd.
|
|
|
|
Model number
|
LYT9400ZFG
|
|
|
Main Dimension
|
|
|
|
Outer Dimension
|
12000*2500*4000mm
|
|
|
Payload
|
30-45t
|
|
|
Tank Body：
|
|
|
|
|
|
|
|
Tank Shell
|
Q235 thickness=2.8mm
|
|
|
Bulkhead & end plate
|
Q235 thickness=4mm
|
|
|
Manhole Cover
|
2 PCS standard manholes, 500 mm diameter, Henghe brand, China
|
|
|
Discharge Valve
|
4” butterfly valve
|
|
|
Compressor
|
air supply
|
|
|
Discharge Pipe
|
3 or 4 inch rubber hose, lpcs,6m/each
|
|
|
Chasis
|
|
|
|
Main Beam
|
Q345B
|
|
|
Axle
|
3 axles
|
|
|
Landing gear
|
28 ton two speed telescopic manual landing gear
|
|
|
King Pin
|
JOST 2.00 or 3.5 inch
|
|
|
Suspension
|
Mechanical suspension Air suspension
|
|
|
Brake
System |
WABCO RE6 relay valve;T30/30+T30 Spring brake chamber,45L air chamber
|
|
|
Rim
|
9.0*22.5 steel disc wheel, 10 holes ISO, 12 pcs.
|
|
|
Tire
|
Triangle brand, 12.00R22.5, 12 pcs
|
|
|
ABS
|
Optional
|
|
|
Electrical system
|
Voltage: 24 Volt
Receptacle: 7 way socket standard, China Front lamp: White Side marker lamp: White & Red |
|
|
Welding Standard
|
All welding are to be done by qualified welder per applicable national standard
|
|
|
Tool box
|
1 pc
|
|
|
Reflector
|
Per customer requirement
|
|
|
Painting
|
Shot blast at Standard SA 2.5 prior to application of primer, polyurethane top coat. Color advised by customer
|
|
|
Shipping Terms
|
1 unit per package by bulk vessel or roro ship
|
|
