Quick Details
-
Sensor type:
-
Fuel cell alcohol sensor, Module replaceable
-
Test Range:
-
0.000-2.000mg/l (0.400%B.A.C; 4.000%oB.A.C; 4.000g/l;)
-
Dimension lXbXh::
-
(mm) 250X105X400
-
Indication manner:
-
mg/l,mg/100ml,g/l ,%BAC,%oBAC optional
-
Coin for single time:
-
0-15 (For 0, the tester can be tested without coin).
-
Coin diameter:
-
20mm-28mm
-
Coin thickness:
-
1.2mm-2.5mm
-
Coins Capacity:
-
about 200 pieces
-
Breath sampling time:
-
about 5 seconds continuous breath
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Diyatel
-
Model Number:
-
AT319
-
Sensor type:
-
Fuel cell alcohol sensor, Module replaceable
-
Test Range:
-
0.000-2.000mg/l (0.400%B.A.C; 4.000%oB.A.C; 4.000g/l;)
-
Dimension lXbXh::
-
(mm) 250X105X400
-
Indication manner:
-
mg/l,mg/100ml,g/l ,%BAC,%oBAC optional
-
Coin for single time:
-
0-15 (For 0, the tester can be tested without coin).
-
Coin diameter:
-
20mm-28mm
-
Coin thickness:
-
1.2mm-2.5mm
-
Coins Capacity:
-
about 200 pieces
-
Breath sampling time:
-
about 5 seconds continuous breath
Product Description
Specifications:
Sensor type Fuel cell sensor
Test Rang: 0.000-2.000mg/L BrAC
0.000-0.400% BAC
0.000-4.000‰ BAC
0.000-4.000g/L BAC
Alarming level:
Warning level: 0.090mg/L (could be modified)
Danger level: 0.250mg/L (could be modified)
Accuracy: +/-0.005 at 0.05BAC%
Working environment:
Temperature: 0oC~50oC Humidity:<95%RH (No Dews)
Power AC110-220V 50-60Hz
Calibration no necessary,well pre-calibrated sensor module changeable
Dimension L x B x H: 250mm x 105mm x 400mm
Indication manner:mg/l;mg/100ml;g/l ;%BAC;‰BAC optional
Coin for single time: 0-15
Coin specification:
Diameter:20mm-28mm,thickness:1.2mm-2.5mm
Coins Capacity;about 600 pieces:
Bill width:62-72mm: Bill capacity:600pcs
Straw capacity:200pcs(⊄<=7mm)
Breath sampling time:about 5 seconds continuous breath
Sensor type Fuel cell sensor
Test Rang: 0.000-2.000mg/L BrAC
0.000-0.400% BAC
0.000-4.000‰ BAC
0.000-4.000g/L BAC
Alarming level:
Warning level: 0.090mg/L (could be modified)
Danger level: 0.250mg/L (could be modified)
Accuracy: +/-0.005 at 0.05BAC%
Working environment:
Temperature: 0oC~50oC Humidity:<95%RH (No Dews)
Power AC110-220V 50-60Hz
Calibration no necessary,well pre-calibrated sensor module changeable
Dimension L x B x H: 250mm x 105mm x 400mm
Indication manner:mg/l;mg/100ml;g/l ;%BAC;‰BAC optional
Coin for single time: 0-15
Coin specification:
Diameter:20mm-28mm,thickness:1.2mm-2.5mm
Coins Capacity;about 600 pieces:
Bill width:62-72mm: Bill capacity:600pcs
Straw capacity:200pcs(⊄<=7mm)
Breath sampling time:about 5 seconds continuous breath
Specification
|
item
|
value
|
|
Place of Origin
|
China
|
|
Province
|
Guangdong
|
|
Brand Name
|
Diyatel
|
|
Model Number
|
AT319
|
|
Sensor type
|
Electrochemical (fuel cell) alcohol sensor, Module changeable
|
|
Work temperature
|
-10oC-50oC
|
|
Work humidity
|
<95%RH (No Dews)
|
|
Battery
|
2XAA NiMH batteries
|
|
rating capacity
|
2.1AH
|
|
Dimension lXbXh
|
(mm) 250X105X400
|
|
Coin for single time
|
0-15 (For 0, the tester can be tested without coin)
|
|
Coin diameter
|
20mm-28mm
|
|
Coin thickness
|
1.2mm-2.5mm
|
|
Breath sampling time
|
about 5 seconds continuous breath
|
