Quick Details
-
Video/Audio Input:
-
VGA /3.5mm Jack
-
Video Codec:
-
H.265/H.264 AVC Base/Main/High
-
Audio Codec:
-
AAC/AAC+/AAC++/MP3/MP2/AC3/G.711A/U
-
Video Output:
-
1080P60
-
Video/Audio Bitrate:
-
0.16-32Mbps/32-384Kbps
-
Ethernet Port:
-
1000M
-
Protocol:
-
srt/utp/http/rtsp/rtmp/udp/rtp/m3u8/flv
-
Power:
-
DC 9-12V 1A or 5V 2A
-
Manager:
-
Website or CGI command
-
Lantency Time:
-
<100ms
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Unisheen
-
Model Number:
-
BM3350VGA
-
Video/Audio Input:
-
VGA /3.5mm Jack
-
Video Codec:
-
H.265/H.264 AVC Base/Main/High
-
Audio Codec:
-
AAC/AAC+/AAC++/MP3/MP2/AC3/G.711A/U
-
Video Output:
-
1080P60
-
Video/Audio Bitrate:
-
0.16-32Mbps/32-384Kbps
-
Ethernet Port:
-
1000M
-
Protocol:
-
srt/utp/http/rtsp/rtmp/udp/rtp/m3u8/flv
-
Power:
-
DC 9-12V 1A or 5V 2A
-
Manager:
-
Website or CGI command
-
Lantency Time:
-
<100ms
Product Description
| Feature | *1x VGA(WUXGA)/1xVGA Out(hold during power off) *Up to 1920x1200 *SRT/RTSP/RTMPS/UDP/NVR etc *Private Low Lantency Protocol UTP *Video Rotate,Flip,Mirror,Clip *Separate Audio or Video Stream *Play Stream on Browser *Customizable |
| Video | |
| Input/Output Loop | 1x VGA(WUXGA)/1xVGA(hold during power off) |
| Resolution | 1920x1200P60,1920x1080@60P/50p,1920x1080@60i/50i/1280x720@60p/50p,1680x1050,1600x1200,1600x900,1440x900,1400x1050,1366x768,1360x768,1280x1024,1280x960,1280x800,1280x768,1280x720,1280x600,1152x864,1024x768,800x600 720x576i/720x480i,640x480,320x480,352x288,240x320,176x144,160x120,128x96,88x72 |
| Encoding | H.265/H.264/AVC Baseline/Main/High Profile Level 4.2 |
| Encoding Output FPS | 1080P60(only input 1080P60) |
| Data Rate | 0.16Mbps~32Mbps |
| Rate Control | CBR/VBR |
| GOP | 5-300 |
| Advanced Pretreatment | De-interlacing, Image Enhancement,Noise Reduction, Sharpening,Video Rotate,Flip,Mirror,Clip |
| Latency Time | 100ms |
| Audio | |
| Input/Output Loop | 1x3.5mm/1.3.5mm |
| Encoding | AAC/AAC+/MP3/MP2/AC3/G711.A/G711.U |
| Sampling rate | 44100/48000 Hz |
| Bit-rate | 32K/48K/64K/96K/128K/160K/192K/384K |
| Sampling precision | 24 bit |
| System | |
| Ethernet | 1000M |
| Protocol | SRT UTP HTTP RTSP RTMP HLS FLV UDP multicast/unicast |
| control interface | Website |
| Genernal | |
| Dimension (L×W× H) | 105x152(173)x28mm |
| Net Weight | 0.3kg |
| Temperature | 0-45(work),-20-80(storage) |
| Power | 12V DC 1A |
| Consumption | 5w |
