Quick Details
-
Model Number:
-
2W31/41
-
Brand Name:
-
YONGCHUNG
-
application:
-
RO system,air compressor,railway system
-
structure:
-
pilot operated diaphragm
-
port:
-
3/8'-2'
-
pressure:
-
0-10bar
-
body:
-
brass and stainless steel
-
coil:
-
ip65
-
power:
-
AC22VA;DC17W
-
life time:
-
300000 times
-
place of origin:
-
ningbo,china
Quick Details
-
Port Size:
-
3/8'-2'
-
Warranty:
-
1 year
-
Place of Origin:
-
Zhejiang, China
-
Model Number:
-
2W31/41
-
Brand Name:
-
YONGCHUNG
-
application:
-
RO system,air compressor,railway system
-
structure:
-
pilot operated diaphragm
-
port:
-
3/8'-2'
-
pressure:
-
0-10bar
-
body:
-
brass and stainless steel
-
coil:
-
ip65
-
power:
-
AC22VA;DC17W
-
life time:
-
300000 times
-
place of origin:
-
ningbo,china
|
Characteristic :
|
• Direct lifting diaphragm structure, low power
• Min operated pressure 0 bar |
|
|
|
|||
|
Medium:
|
Air,water,oil
|
|
|
|
|||
|
Temperature:
|
NBR:-10℃~80℃
EPDM:-30℃~120℃
VITON:-30℃~150℃ |
|
|
|
|||
|
Pressure:
|
0-1.0Mpa
|
|
|
|
|||
|
Port size:
|
3/8'-2'
|
|
|
|
|||
|
Port thread:
|
G, Flange
|
|
|
|
|||
|
Orifice(mm):
|
12-50
|
|
|
|
|||
|
Voltage:
|
DC-12V; 24V
AC:24V,120V,220V
|
|
|
|
|||
|
Tolerance:
|
±10%
|
|
|
|
|||
|
Coil:
|
S91B,22VA(AC),16W(DC),IP65,100% ED
|
|
|
|
|||
