Quick Details
-
Warranty:
-
30 year
-
Brand Name:
-
Bluesun
-
Model Number:
-
BSM550M10-72HPH
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2094*1138*35mm
-
Weight:
-
32KGS
-
Back Sheet:
-
TPT 0.3mm
-
Glass:
-
3.2mm (0.13inches) AR Coating Tempered Glass
-
Frame:
-
Anodized Aluminium Alloy
-
Application:
-
Solar Home System
-
Temperature Coefficient Pmax:
-
-0.36%/°C
-
IP protection:
-
IP67
-
Operating Temperature:
-
-40°C~ +85°C
-
Junction box:
-
CE TUV INMETRO CEC
-
Snow/Wind Loading:
-
5400Pa/2400Pa
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell, Bifacial, Double-glass, All Black, N-TYPE, TOPCON
-
Panel Efficiency:
-
21.3%
-
Warranty:
-
30 year
-
Brand Name:
-
Bluesun
-
Model Number:
-
BSM550M10-72HPH
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2094*1138*35mm
-
Weight:
-
32KGS
-
Back Sheet:
-
TPT 0.3mm
-
Glass:
-
3.2mm (0.13inches) AR Coating Tempered Glass
-
Frame:
-
Anodized Aluminium Alloy
-
Application:
-
Solar Home System
-
Temperature Coefficient Pmax:
-
-0.36%/°C
-
IP protection:
-
IP67
-
Operating Temperature:
-
-40°C~ +85°C
-
Junction box:
-
CE TUV INMETRO CEC
-
Snow/Wind Loading:
-
5400Pa/2400Pa
Click on the image to learn more
Bluesun Project
Advantages of Bluesun
Products Description
Bifacial PERC Solar Cell
For a bifacial PERC cell, the Al back surface field is replaced by Al grid, hence render the majority of rear side transparent which enable the cell to absorb light and generate electricity from both sides.
For a bifacial PERC cell, the Al back surface field is replaced by Al grid, hence render the majority of rear side transparent which enable the cell to absorb light and generate electricity from both sides.
|
ELECTRICAL PARAMETERS at STC
|
|
|
|
|
|
|||||
|
Module Type
|
BSM530M10-72HBD
|
BSM535M10-72HBD
|
BSM540M10-72HBD
|
BSM545M10-72HBD
|
BSM550M10-72HBD
|
|||||
|
Maximum Power (Pmax/W)
|
530
|
535
|
540
|
545
|
550
|
|||||
|
Operating Voltage (Vmpp/V)
|
41.32
|
41.48
|
41.64
|
41.8
|
41.96
|
|||||
|
Operating Current (Impp/A)
|
12.83
|
12.9
|
12.97
|
13.04
|
13.11
|
|||||
|
Open-Circuit Voltage (Voc/V)
|
49.32
|
49.46
|
49.6
|
49.76
|
49.92
|
|||||
|
Short-Circuit Current (Isc/A)
|
13.72
|
13.79
|
13.86
|
13.93
|
14
|
|||||
|
Module Efficiency (%)
|
20.5
|
20.6
|
20.8
|
21
|
21.2
|
|||||
|
Performance at NMOT
|
|
|
|
|
|
|||||
|
Maximum Power (Pmax/W)
|
395
|
398
|
402
|
406
|
410
|
|||||
|
Operating Voltage (Vmpp/V)
|
38.6
|
38.7
|
38.8
|
39
|
39.1
|
|||||
|
Operating Current (Impp/A)
|
10.24
|
10.3
|
10.36
|
10.41
|
10.47
|
|||||
|
Open-Circuit Voltage (Voc/V)
|
46.4
|
46.5
|
46.7
|
46.8
|
47.0
|
|||||
|
Short-Circuit Current (Isc/A)
|
11.06
|
11.12
|
11.17
|
11.23
|
11.28
|
|||||
|
|
|
|
|
|
||||||
