Quick Details
-
Positioning Accuracy (mm):
-
0.01 mm
-
Travel (X Axis)(mm):
-
600 mm
-
Travel (Y Axis)(mm):
-
400 mm
-
Repeatability (X/Y/Z) (mm):
-
0.01 mm
-
Spindle Motor Power(kW):
-
2.2
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
LY
-
Voltage:
-
220V/110V
-
Dimension(L*W*H):
-
810X640X480mm
-
Power (kW):
-
2.2
-
Weight (KG):
-
70
-
Communication interface:
-
USB port
-
Power:
-
2.2KW
-
Weight:
-
90kg
-
After-sales Service Provided:
-
Online support
-
Certification:
-
CE ISO
Quick Details
-
Working Table Size(mm):
-
600*400
-
Machine Type:
-
CNC Router
-
Range of Spindle Speed(r.p.m):
-
1 - 24000 rpm
-
Positioning Accuracy (mm):
-
0.01 mm
-
Travel (X Axis)(mm):
-
600 mm
-
Travel (Y Axis)(mm):
-
400 mm
-
Repeatability (X/Y/Z) (mm):
-
0.01 mm
-
Spindle Motor Power(kW):
-
2.2
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
LY
-
Voltage:
-
220V/110V
-
Dimension(L*W*H):
-
810X640X480mm
-
Power (kW):
-
2.2
-
Weight (KG):
-
70
-
Communication interface:
-
USB port
-
Power:
-
2.2KW
-
Weight:
-
90kg
-
After-sales Service Provided:
-
Online support
-
Certification:
-
CE ISO
Mini CNC Router 6040Z 2.2kw with water tank Engraving Milling Machine
The CNC router is suitble for Industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes.
The cnc router is designed for large area engraving work such as Industrial or Hobby Prototype Building, Building Model Making, PCB, Advertising Signs, Artwork, Crafts, Aircraft Models, RC Model parts, etc. So, you can do engraving work at office or home.
Model and Technical Parameters
|
MODEL |
6040Z with water tank |
|||
|
Attribute |
4axis-USB |
|
||
|
Axis |
4axis |
|
||
|
Interface |
USB port | |||
|
Limit switch |
Yes | |||
|
Tool auto-checking |
Yes | |||
|
Spindle Motor: |
2.2KW | |||
|
Type of screw |
Ball screw | |||
|
Weigh |
77 | |||
|
Machine Dimensions: |
810X640X480mm |
|||
|
Rack material: |
6061 and 6063 Hard aluminum alloy
|
|||
|
Engraving area: |
600X400mm |
|||
|
Z-Axis Stroke: |
80mm, Engraving depth depends on the length of the tool edge |
|||
|
Acceptable material thickness: |
≤100mm |
|||
|
Rail type: |
Chromeplate shaft + Linear Bearings, Surface hardening 61HRC |
|||
|
Type of screw: |
Ball screw 1605, Pitch 4mm |
|||
|
Spindle motor: |
2.2KW VFD water cooling spindle , 0-24000r/min |
|||
|
Collet type: |
ER20, 6mm Collet |
|||
|
Stepper motor and drive: |
two-phase hybrid stepping motor 57BYGH56-4011YD, 8 segments drive. |
|||
|
Maximum operating speed: |
4000mm/min (Engraving speed : 300-3000mm/min) |
|||
|
Repeat positioning Accuracy: |
0.03mm |
|||
|
Software Compatability: |
Mach3/Emc2/Kcam, (Type3,Wentai, ArtCAM, coppercam) |
|||
|
Command code: |
G code/.nc/.ncc/.tab/.txt |
|||
|
Rotation Axis (4 th Axis) Description: |
Chuck Size: 80mm self-centering chuck Center height: H = 49mm Clamping diameter: 80mm or less Deceleration mode: synchronous wheel / belt Deceleration ratio: 3:1 Stepper motor: 57 type two phase 4 line Positioning accuracy: 0.075 ° |
|||
Water tank is the requisite for engraving jade and metal on engraver;
The tank is made of 304 stainless steel, stable and beautiful;
Features:
a. The water tank has integrated low frame which can be removed
b. The size and weight of the tank are as follows. The hole is mainly applicable to the LY brand engraving machine,if you want to use other brands of engraving machines, you need to deal with it yourself;
c. The machine with installation of water tank , before shipment, has done a good deal of water leak-proof treatment. If you just buy a water tank, you need install it yourself and do the water leak-proof treatment;
