- Product Details
- {{item.text}}
Quick Details
-
Internal Dimensions(l x W x H)(mm):
-
11500*2110*2290
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
LSXC
-
Tank Material:
-
Q235/5.0mm
-
Beam Material:
-
Q235B
-
Shape:
-
Rectangular
-
Payload:
-
50,000 KG
-
Gross Vehicle Weight:
-
60,000 KG
-
Tare Weight:
-
10,000 KG
-
End Thickness:
-
6.0mm
-
Corrugated Plate:
-
1.8mm
-
Tank Thickness:
-
5.0mm
-
Design Pressure:
-
0.175 Mpa
Quick Details
-
Type:
-
Tank Container
-
Capacity:
-
520000
-
External Dimensions(l x W x H)(mm):
-
11900*2210*2390
-
Internal Dimensions(l x W x H)(mm):
-
11500*2110*2290
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
LSXC
-
Tank Material:
-
Q235/5.0mm
-
Beam Material:
-
Q235B
-
Shape:
-
Rectangular
-
Payload:
-
50,000 KG
-
Gross Vehicle Weight:
-
60,000 KG
-
Tare Weight:
-
10,000 KG
-
End Thickness:
-
6.0mm
-
Corrugated Plate:
-
1.8mm
-
Tank Thickness:
-
5.0mm
-
Design Pressure:
-
0.175 Mpa
Product Description
Details Images
Specification
|
Item
|
Specification
|
|
Tank Material
|
Q235/5.0mm
|
|
Beam Material
|
Q235B
|
|
Shape
|
Rectangular
|
|
Payload
|
50,000 KG
|
|
Gross Vehicle Weight
|
60,000 KG
|
|
Tare Weight
|
10,000 KG
|
|
End Thickness
|
6.0mm
|
|
Corrugated Plate
|
1.8mm
|
|
Tank Thickness
|
5.0mm
|
|
Design Pressure
|
0.175 Mpa
|
|
Design Temperature
|
-40°C to 230°C
|
|
Working Pressure
|
0.09 Mpa
|
|
Working Temperature
|
230°C
|
|
Test Pressure
|
0.26 Mpa
|
|
Corrosion Resistance
|
0
|
|
Air Tightness Test Pressure
|
0.12 Mpa
|
|
Vacuum Test Pressure
|
0.021 Mpa
|
|
Welding Joint Factor
|
1
|
|
Radiographic Testing
|
100% X-RAY
|
|
Manholes
|
2 x DN500
|
|
Discharge Valve
|
1 x DN80
|
|
Wave Guards
|
5 pieces
|
|
Heating Tubes
|
Ø60*3.5 mm
|
|
Heating Tube Flange Connection
|
DN50
|
|
Bitumen Discharge Valve
|
DN80
|
|
Quick Coupler
|
DN80
|
|
Access Ladder and Guardrail
|
Available
|
|
Color
|
Customizable
|
|
Insulation Material and Thickness
|
Rockwool/100mm
|
|
Level Gauge and Thermometer
|
1 each
|
|
Outer Skin Material and Thickness
|
Cold-rolled steel/1.2mm
|
|
Additional Notes
|
- Installation of 2 manhole assemblies, 2 breathing valves, and 1 manual 4-inch disc valve at the bottom of the tank
|
Packing and Transport
Certifications
Customer visits
FAQ
Q: who are we?
A: We are based in Henan, China, start from 2019,sell to Eastern Europe(40.00%),Western Europe(12.00%),Southeast
Asia(10.00%),Central America(8.00%),Eastern Asia(5.00%),Mid East(5.00%),Northern Europe(5.00%),South America(5.00%),North America(3.00%),Africa(3.00%),Domestic Market(1.00%),South Asia(1.00%),Southern Europe(1.00%),Oceania(1.00%). There are total about 11-50 people in our office.
Q: how can we guarantee quality?
A: Always a pre-production sample before mass production;Always final Inspection before shipment;
Q: what can you buy from us?
A: Tank Container,ISO Tank,iso tank container,40 lpg tank container,iso lng container tank
Q: why should you buy from us not from other suppliers?
A: Henan Lishixin Logistics Equipment Co., Ltd is located in Zhengzhou FTA, Henan Province, China,is specialized in the R & D,mass production and sales of kinds of the 20FT,30FT,40FT ISO Storage Containers and Storage Tanks as well as other special equipments.
Q: what services can we provide?
A: Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
Q: Can i do your agent in our country or some district?
A:Yes,if you quantity is enough,no problem. Sincerely looking forward to cooperate with you !
A: We are based in Henan, China, start from 2019,sell to Eastern Europe(40.00%),Western Europe(12.00%),Southeast
Asia(10.00%),Central America(8.00%),Eastern Asia(5.00%),Mid East(5.00%),Northern Europe(5.00%),South America(5.00%),North America(3.00%),Africa(3.00%),Domestic Market(1.00%),South Asia(1.00%),Southern Europe(1.00%),Oceania(1.00%). There are total about 11-50 people in our office.
Q: how can we guarantee quality?
A: Always a pre-production sample before mass production;Always final Inspection before shipment;
Q: what can you buy from us?
A: Tank Container,ISO Tank,iso tank container,40 lpg tank container,iso lng container tank
Q: why should you buy from us not from other suppliers?
A: Henan Lishixin Logistics Equipment Co., Ltd is located in Zhengzhou FTA, Henan Province, China,is specialized in the R & D,mass production and sales of kinds of the 20FT,30FT,40FT ISO Storage Containers and Storage Tanks as well as other special equipments.
Q: what services can we provide?
A: Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
Q: Can i do your agent in our country or some district?
A:Yes,if you quantity is enough,no problem. Sincerely looking forward to cooperate with you !
