Quick Details
-
Dimension(L*W*H):
-
650*550*1350 mm
-
Weight:
-
310
-
Power (kW):
-
3
-
Product name:
-
High Pressure Hydraulic Hose Crimping Machine
-
Type:
-
Press Crimper
-
Crimping range:
-
1/8"-2"(4mm-51mm Inner Diameter)
-
Crimping force:
-
650T
-
Operational way:
-
Manual Hand Operate Press
-
Color:
-
Customized Color
-
Free dies:
-
7-13 Sets
-
Scale accuracy:
-
0.01mm Hose Crimping Machine
-
System pressure:
-
26MPa / 31.5MPa(Optional)
-
Control System:
-
Manual Or Digital Control
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
HAIFU
-
Voltage:
-
380V/220V
-
Dimension(L*W*H):
-
650*550*1350 mm
-
Weight:
-
310
-
Power (kW):
-
3
-
Product name:
-
High Pressure Hydraulic Hose Crimping Machine
-
Type:
-
Press Crimper
-
Crimping range:
-
1/8"-2"(4mm-51mm Inner Diameter)
-
Crimping force:
-
650T
-
Operational way:
-
Manual Hand Operate Press
-
Color:
-
Customized Color
-
Free dies:
-
7-13 Sets
-
Scale accuracy:
-
0.01mm Hose Crimping Machine
-
System pressure:
-
26MPa / 31.5MPa(Optional)
-
Control System:
-
Manual Or Digital Control
Product Description
New Design High Efficiency Cable Crimping Machine For Workshop Use Dx68 p32 p20 Hydraulic Hose Crimping Machine On Sale
Hydraulic Hose Crimping Machine with High Quality
Crimping machines are usually used for field service for repairs of construction machinery. We supply service machines, which are simple and straight-forward in construction, easy to operate, and highly reliable. It is light weight, so these crimping machines can be easily carried to any location.
INTRODUCTION FOR P32S HOSE CRIMPING MACHINE
P32S has the fabulous crimping features as the 20 series of crimping machines. They are mid-range in terms of power, but compact from the point of view of space requirements. P32S machines provide 6500 kN crimping force in a highly compact, ergonomic design.They are ideally suited for singlepiece production in machine shops, repair workshops etc. All table-top machines can be mounted on a QC Tool Base. Up to 16 die sets can be stored in a base for operator convenience.
TECHNICAL DATA SHEET
|
Model
|
FINN POWER P32S Hydraulic Hose Crimping Machine
|
|
Crimping Range:
|
14 - 87 mm
|
|
Hose Size:
|
6 - 51 mm ( 1/4 - 2" ) 4 Wires
|
|
Crimping Force:
|
6500 kN
|
|
Free Dies:
|
13 Sets
|
|
Accuracy:
|
0.01 mm
|
|
System Pressure:
|
31.5 Mpa
|
|
Oil Pump:
|
2.5L / 5L / 10L (Optional)
|
|
Motor Power:
|
3 / 4 KW
|
|
Voltage:
|
110V/208V/220V/240V/380V/415V (Optional)
|
|
Frequency:
|
50 / 60 HZ
|
|
Max Opening:
|
33 mm
|
|
Hydraulic Oil:
|
T46
|
|
Net Weight:
|
310 KGS
|
|
Gross Weight:
|
330 KGS
|
|
Dimension:
|
650*550*1350 mm
|
|
Packing Volume:
|
0.5 CBM
|
MAIN FEATURES
The P32S hose crimping machine is widely used in hose fitting assembly workshop or on-site repairs service, it may be the most classic equipment for pressing 1/4” to 2” 4 layers hydraulic hoses.
The advanced technology make the crimper offer high accurate fabrication and rapid crimping cycles. There are 13 sets of standard dies, different sizes of dies makes the hose crimper become multipurpose machinery.
In the meanwhile, P32S is equipped with a die rack and quick change tool, they offer lots of convenience to the operators.
The advanced technology make the crimper offer high accurate fabrication and rapid crimping cycles. There are 13 sets of standard dies, different sizes of dies makes the hose crimper become multipurpose machinery.
In the meanwhile, P32S is equipped with a die rack and quick change tool, they offer lots of convenience to the operators.
* Quick change dies tool
* Emergency stop to ensure the safe
* Quick crimping and retracted process
* High quality material and famous brands parts
* Precision formed effect
DETAILED INTRODUCTIONS
SIEMENS MOTOR
P32S is equipped with high quality electricity system. The motor is famous '' SIEMENS'' motor. The advantage is it is more stable and can enjoy the one year world wide after-sale service offered by '' SIEMENS'' company.
HIGH QUALITY HYDRAULIC VALVE SYSTEM
P32S is with high quality, world famous hydraulic valve system - '' Rexroth'' valve system from Germany. With a high hardness spool, the valve works with high stability and has long service life during same working environment.
DIES CHOOSE SHEET
32 series hose crimping machine is with die sets choosing reference sheet in front of the machine on the electric box. It will makes the crimping work more convenient for operators.
DIE SETS RACK
P32S hose crimper can be mounted on a special die sets rack. The rack is able to store 18 sets dies.
Packing & Delivery
Standard Export Plywood
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
